Feature:
1. 7pcs High brightness OSRAM 4IN1 LEDs, RGBW infinite mixture system
2. High light output 840lux @ 7m
3. Compact and lightweight, easy to control
Specification:
Input Voltage: AC90-260V 50/60Hz
LED Quantities: 7PCS OSRAM 12W 4-IN-1 LEDs (R, G, B, W)
Control Signal: DMX512, master-slave and sound activated or auto operation
Control Channel: 15 DMX channels
Power Consumption: 120W
60,000 hours life span for LEDs and low power consumption
Intelligent temperature sensor for LEDs(over heat protection)
High efficiency 8 degree optic lens
Color range with 16.7 millions additive RGBW colors
High light output as 840LUX@ 7M at full
0-100% smooth linear dimmer with flicker free
20t/s strobe effect with variable speed
Pre-programmed random strobe and pulse effects
15 DMX Channels
Built-in programs with macro effects
DMX512, master-slave and sound activated controllable or auto operation
High definition blue TFT LCD display
Quiet, smooth and fast PAN/TILT movement
Low noise and efficient FAN cooling system
540° PAN and 250° TILT movement
Scan position memory, auto reposition after unexpected movement
Compact size with only 4.9KG body and 310mm in height
IEC power connector
45ºC max ambient temperature
IP20 protection rating
3-Pin XLR DMX input/output
Dimensions: 152(D)*265(W)*310(H)mm
Packing Dimensions:260(D)*320(W)*335(H)mm
Net Weight: 4.9kg
Gross Weight: 7kg
DMX Channel:
| CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
| FUNCTION 15 | Pan | Tilt | Pan Fine | Tilt Fine | Dimmer | Strobe | Red | Green | Blue | White | Colors | Macros | Macros
Speed | PAN/TILT
Motor Speed | Reset &
sound control |
Our advantages are:
1 ) with fast-lock, easy to operate the lights; Esp for lots of quantities.
2 ) with back light, after 10s, the screen light will be off, this function is highly required in some Europe countries;
3 ) with DMX 9/12/16CH, with advanced program & inner configuration, below enclosed the photos for your reference, much more stable than the one with 15 DMX Channel;
4 ) with high power consumption, with real Osram LEDs, with a strong beam effect, splendid effect.
Guangzhou Baiyun Popular Stage Light Equipment Factory is a professional stage lighting manufactory which provides integrated services of research, production, marketing, after-sales inquiry, repair and maintenance. Our equipment are widely used in professional theater, entertainment centers, bars, parks, clubs, nightclubs and multifunctional units of conference halls. Compliant with CE and RoHS standards, our products main involve LED moving head lights, LED PAR lights, controllers, Moving head light, etc.
with strong beliefs in "Practical, Professional & Powerful" to the products, the company provides remarkably superb lighting Performance to all Professional Audience.
Hope we can grow together on the coming days.
