Super slim LED panel lamp pkw square 6W, ming mounted square Shape slim LED panel light with CE & RoHS, High Power ming mounted square Slim LED Panel Ceiling lights 6W LED slim Panel Lamp
Products name:
Light Source: LED
Item Type: LF-SQ120-B
LED Light Source: SMD 2835
Warranty(Years): 3
Input Voltage(V): AC 100V-240V
Lamp Power(W): 6
Lamp Luminous Flux(lm): 420lm± 10%
Lamp Luminous Efficiency(lm/w): 90
CRI (Ra>): 75
Color Temperature(CCT): White(6000-6500K)/WARM WHITE(2700-3000K)
Working Temperature(? ): -20 - +55
Working Lifetime(Hour): 30000H
Lamp Body Material: DIE-CASTING ALUMINUN
IP Rating: IP40
Certification: CE&RoHS
Place of Origin: China (Mainland)
LED Qty: 15PCS SMD2835
Working Ambient Humidity: <85%
Working Ambient Temperature: -20~~+55
Face Size: 120*120M
Installation
A, embedded installation
The circlip is arranged on the LED lamp back, fixed with M4 screw, the ceiling opening, using the circlip on the ceiling, the size of holes as shown in fig.
B, ceiling mounted:
1, as shown in Figure 1, the ceiling mounted bracket is arranged on the back of LED lamps.
2, with 4 M4 expansion screws according to the bracket 4 10 hole position is fixed on the ceiling.
3, the LED flat lamp mounting bracket through the expansion screw, the lamp in the direction of oval hole mobility, attached to the ceiling.
4, the 4 expansion screw is arranged on the M4 lamp fixing nut.
C, Suspended installation:
The product with the wire rope accessories package within the LED lighting was installed in the ceiling.
Packaging & Delivery
Packaging Detail: 245*245*60mm/PCS
Delivery Detail: 1-3 working days for samples, 3-15 days for mass production
Attention:
1, the product in the course of their work, try not to touch the hands of the lamp body, to prevent burns
2, try not to use the product in humid environment, so as to avoid the adverse
Note: All information is subject to change without notice. If you have any questions, please contact the supplier.
