4W 8W 12W 16W SMD COB Dimmable Sensor LED Down LightFTS-TD1501-2.5''
A, LED Down Light Descriptions:
LED down light adopts high quality, high brightness LED bulb, with good color rendering, dia-casting aluminum quality make the light body more beautiful and durable. Further more the LED is no flicker, no red ultraviolet, no damage
B, LED Down Light Feature
1, Secure built-in constant current circuit employed.
2, Take the advantage of stability of the power supply, avoid the LED failure caused by the voltage surge, shock or other damages due to the unsteadiness of the constant current driver.
3, High power efficiency. Conversion rate>92%, improved by 6% comparing with the conventional constant current driver.
4, Easy connection. Any quantity of Ceiling light can be wired in parallel connection within the rated wattage of the Power supply and all the ceiling light can work separately.
5, Proprietary design for excellent thermal management and lumen maintenance.
6, High output white, commercial white and warm white LED
7, Reverse polarity protected.
8, 2 year warranty.
LED down light adopts high quality, high brightness LED bulb, with good color rendering, dia-casting aluminum quality make the light body more beautiful and durable. Furthermore the LED is no flicker, no red ultraviolet, no damage. Replacement bulbs for traditional lightings, especially for museums, art galleries, restaurants, hotels, certain sales counters, bars, celebration places where UV or IR radiation is undesirable.
|
Item No. |
Specification |
|
FTS-TD1501-2.5'' |
LED Power: 4W
Size:DIA92*54mm
Chip:2835SMD Taiwan Epistar 15LEDs
Lumens:25lm/SMDLED 350-400lm
Beam Angle:120
Hole Cut:75mm
Marerail: Aluminium+Acrylic
Input voltage:AC85-265V, 50HZ-60HZ
LED Color:Warm white,Pure White |
|
FTS-TD3001-4'' |
LED Power: 8W
Size:DIA130*65mm
Chip:2835SMD Taiwan Epistar 30LEDs
Lumens:25lm/SMDLED 600-650lm
Beam Angle:120
Hole Cut:115mm
Marerail: Aluminium+Acrylic
Input voltage:AC85-265V, 50HZ-60HZ
LED Color:Warm white,Pure White |
|
FTS-TD5001-5'' |
LED Power: 12W
Size:DIA160*65mm
Chip:2835SMD Taiwan Epistar 50LEDs
Lumens:25lm/SMDLED 1000-1050lm
Beam Angle:120
Hole Cut:140mm
Marerail: Aluminium+Acrylic
Input voltage:AC85-265V, 50HZ-60HZ
LED Color:Warm white,Pure White |
|
FTS-TD7501-6'' |
LED Power: 16W
Size:DIA180*74mm
Chip:2835SMD Taiwan Epistar 75LEDs
Lumens:25lm/SMDLED 1350-1400lm
Beam Angle:120
Hole Cut:165mm
Marerail: Aluminium+Acrylic
Input voltage:AC85-265V, 50HZ-60HZ
LED Color:Warm white,Pure White |
