Feature
1. Case of Led Ceiling Light: the high thermal conductivity aluminum alloy shell
2. Energy saving, environmental protection
3. Energy saved up to 50%. High brightness, even lighting output
4. Surface temperature: <40°C
5. LED working temperature: <45°C; Environmental temperature: -20~+50°C
6. Light decay: 2 - 3%/5000H
7. No UV and radiation
8. AC100-240V working directly, Constant current power supply drive, through the CE certification
9. Instant start, no flickering, no humming
10. Installation of Led Ceiling Light: embedded, hanging or lifting.
Led Ceiling Light Warranty
The validity of the Led Ceiling Light warranty is subject to the correct storage, installation, operation and maintenance of this product. Failing to comply with the storage, installation operation and maintenance routines will make the warranty invalid.
Adavantages
Using high brightness LEDs as light source, the frame is aluminum profile with simple and fashion appearance, and never change its color.
Low-voltage constant current driver. Long life span. Excellent distribution shows high luminous efficiency and eurhythmic lights, it would be more soft and equable. Great design ensures LEDs working stable and control light decay.
The high transmittance Acrylic board shows soft and high bright. Turn on instant, no stroboscopic, no noise, no lead and Mercury.
The Led Ceiling Light is easy to install, which can be mounted directly instead of ceiling panels, also can be hung through holes on the back of lights.
Applications of Led Ceiling Light
Hotel, meeting rooms, offices, hospitals, schools and other energy-saving places.
Package
With the proper power supplier, put in an transparent bags, the Led Ceiling Light is packed by the white box which is 190*190mm. Then put in carton per 24pcs.
|
Details of Ephan Led Ceiling Light |
|
Model |
EPP-28S6W-4in |
|
Size(mm) |
120*14 |
|
Hole(mm) |
100 |
|
Power |
6W |
|
LED Type and Quantity |
40pcs SMD2835 |
|
Luminous |
500~600lm |
|
Inner package |
185*185*45mm white box |
|
Warranty |
2 years |
|
LEDs Lumen Decrease |
|
Testing condition: testing for light work lasting |
|
Operating time(hours) |
Lumen decrease(%) |
|
500 |
0 |
|
1000 |
0 |
|
1500 |
0 |
|
2000 |
1 |
|
3000 |
1 |
|
5000 |
2 |
|
Electrical Characteristic |
|
All data is under 25 °C , unless otherwise specified. |
|
Symbol |
Parameter |
Unit |
Min. |
Typ. |
Max. |
|
Vin |
Input Voltage |
V |
90 |
220 |
265 |
|
Lin |
Input Current |
mA |
20 |
-- |
65 |
|
P |
Power Consumption |
W |
5 |
6 |
8 |
|
% |
Power Factor |
|
0.85 |
0.9 |
0.98 |
|
F |
Input Frequency |
Hz |
50 |
-- |
60 |
|
Top |
Opearting temperature range |
°C |
-20 |
-- |
50 |
|
Tstg |
Storage temperature range |
°C |
-20 |
-- |
50 |
|
Photometry Characteristic |
|
All data is under 25 °C , unless otherwise specified. |
|
Symbol |
Parameter |
Unit |
Min. |
Typ. |
Max. |
|
Br |
Lumen output |
lm |
500 |
550 |
600 |
|
lv |
Lux at 1m |
lx |
250 |
275 |
300 |
|
lv |
Lux at 1.5m |
lx |
125 |
140 |
150 |
|
lv |
Lux at 2m |
lx |
62 |
70 |
75 |
|
lv |
Lux at 3m |
lx |
30 |
35 |
40 |
|
CT |
Color temperature |
K |
2700 |
-- |
7500 |
|
CRI |
Color rendering index |
-- |
70 |
75 |
-- |
