Appearance of structure: The products both in generous and elegance, The main component of the lamp is made up of high intensity PC, With the characteristic of light weight and high safety insurance; Match special installation tool, more flexible with the environment, can be installed on the ceiling directly.
Light Source: Adopt high brightness SMD 2835 Leds, optical line through high transmission, to form uniform plane surface after the modulation of the diffusion Shell, the light efficiency of the whole light can reach 80 Lm/W, more energy saving, long life span, low cost in maintain, can take the replacement of the traditional fluorescent Mounted ceiling light which in 10-16 inches.
Light Distribution: The technical of the light distribution make the point led into a surface light source, increase the shiny surface, remove the glare, sublime the effects of the sight, overcome the weary of sight; The cover adopt imported PMMA, average in the optical line, prevent from the giddy, make the light more soft.
Power Supply: The products drived by alternating current, the driver in the design of wide Voltage(AC100-240V/47-63Hz), Can be used all over the world. Constant power output, a wonderful combination with Led Light Source.
Applications: Meeting Room\Offices\Hotels\Home Lighting and so on.
Parameters:
Item No.: SY490CLI-40
Power consumption(W): 40W
Luminous flux (Lm): 3200-3400Lm
LED type: High power SMD LED(420pcs SMD2835)
Power factor: ≥ 0.9
Input voltage (V): 220-240AC
CRI(Ra): ≥ 80
Color temperature (K): 3000K 4000K 5000K
Average beam angle (50%): 109.6°
Material: White PC housing, PC base with patent, high efficiency LED driver, high transmission diffuser.
Working temperature (C): -20~40C
IP rating: IP44
LED life span (H): 50000H
Dimension(mm): 490*77mm
Net weight(kg): 1.5kg/pc
Application:
Bed rooms, living room, lift areas, corridors, and passageway, hospitals, banks etc.
|
Item No. |
SY490CLI-40 |
|
Power consumption(W) |
40W |
|
Luminous flux (Lm) |
3200-3400Lm |
|
LED type |
High power SMD LED(420pcs SMD2835) |
|
Power factor |
≥ 0.90 |
|
Input voltage (V) |
220-240AC |
|
CRI(Ra) |
≥ 80 |
|
Color temperature (K) |
3000K 4000K 5000K |
|
Average beam angle (50%): |
109.6 ° |
|
Material |
White PC housing, PC base with patent, high efficiency LED driver, high transmission diffuser. |
|
Working temperature (C) |
-20~40C |
|
IP rating |
IP44 |
|
LED life span (H) |
50000H |
|
Dimension(mm) |
490*77mm |
|
Net weight(kg) |
1.5kg /pc |
|
Application |
Bed rooms, living room, lift areas, corridors, and passageway, hospitals, banks etc. |
