Yiyang PengCheng technology development Co., Ltd, was founded in 1988, and is an enterprise specialized in development & production of Aluminum Electrolytic capacitors. Our company is engaged in radial electronytic capacitor research and development, production, marketing and service. Adhering the management philosophy of environment protection and energy saving, PengCheng has been one of the most potential manufactures in the aluninum eletrolytic capacitor field in YIYANG, HUNAN.
We have dedicated in providing high quality Aluminum Electrolytic capacitors, perferct commercial lighting solution, we have strong technique power and advanced development and production equipments. Our Main products is Aluminum Electrolytic capacitor, which are widely used in LED lamp/light, save lamp, High Ripple Current.
Our main products including: Radial capacitors, general use Aluminum Electrolytic capacitors, LED driver Aluminum Electrolytic capacitors, light capacitors, high capacitance capacitors, Ballast capacitor which are wildely used in battry, electrical household appliances, lighting, etc. RoHS compliant, long life, low leakage and high stability, and wide range of working temperatrue. Which make us to be one of the top rank of the Aluminum Electrolytic capacitors suppliers. Through persevering efforts, we have passed ISO9001: 2008, ISO14000: 2001, RoHS certificates. Due to the top quality products, reasonable prices and sincere service, we have also won the trust and support of our customers.
We have got experienced sales and after service system, and products are sold in India and we are planning for developing American, Asia marketing, ect. We also have offices in Beijing, ShenZhen, ZhongShan, HangZhou and some other domestic cities.
We develop stable and steady at present and believes credibility and integrity will help make an achievement of future. In the rising economic wave, our company will as just in past stick to the business philosophy -"being stable, credibility and integrity", to develop more new products and improve the quality. Meanwhile, we will improve our after sales system, aims to serve customers with high quality products and service in return for their trust and support.
We want to cooperate with agents and dealers across the world, while the OEM, ODM, and foreign trading companies are welcome to negotiate about the matter concerning cooperation. Welcome to contact us.
|
Series |
Feature |
Terminal Type |
Rated Voltage range(V) |
Norminal Capacitance range(μF) |
Operationg Temperature range (°C) |
|
|
|
|
|
|
|
|
CD11G |
General,specially designed for energy-save lamp.105°C,3000hrs |
Radial |
160-450 |
1~100 |
-40~+105 |
|
CD11GA |
High-temp,specially designed for energy-save lamp.105°C,5000hrs |
Radial |
160-450 |
1~100 |
-40~+105 |
|
CD11GC |
Specially designed for electronic ballast and energy-save lamp,high ripple current,extremely long life .105°C,8000hrs(or 130°C,2000hours) |
Radial |
160-450 |
1~100 |
-40~+105 |
|
CD11GE |
Specially designed for electronic ballast and energy-save lamp,high ripple current,extremely long life .105°C,12000hrs(or 130°C,3000hours) |
Radial |
160-450 |
1~100 |
-40~+105 |
|
|
|
Item |
Characteristics |
|
Operating Temperature range(°C) |
-40~+105°C(160~250V) -25~+105°C(350~450V) |
|
Rated voltage(V) |
160~450V.DC |
|
Capacitance Tolerance |
-10%~+20% |
|
Leakage current |
0.01CV or 3μA whichever is greater(at 20°C ,after 2minuters) |
|
Dissipation Factors(25°C,120HZ) |
WV |
160V-400V |
450V |
|
tgδ |
0.08 |
0.10 |
|
Load life |
After application of the rated voltage plus the rated ripple currentat 105°C,the capacitor shall meet the below requirement: |
|
Time |
8000 hours |
|
|
Leakage current |
Not more than the specified value |
|
Capacitance change |
within±20%of the initial value |
|
|
Dissipation factor |
Not more than 200% of the specified value |
|
Shelf life (105°C) |
After leaving capacitors under no load at +105°C for 1000 hours ,capacitors shall meet the specified value for load life characteristics listed below |
|
Time |
1000 hours |
|
|
Leakage current |
Not more than 200%of the specified value |
|
Capacitance change |
within±20%of the initial value |
|
|
Dissipation factor |
Not more than 200% of the specified value |
|
Accelerated durability testing |
At 145°C under the conditions imposed on the capacitor ripple current rating DCrated voltage of 750 hours,after cooling test performance characteristics of the capacitor shall meet the following requirement: |
|
Time |
500 hours |
|
|
Leakage current |
Not more than 200% of the specified value |
|
Capacitance change |
within±20%of the initial value |
|
|
Dissipation factor |
Not more than 200% of the specified value |
|
|
|
Dimensions |
|
ΦD |
Φ8 |
Φ10 |
Φ13 |
Φ16 |
Φ18 |
|
Φd |
0.5 |
0.6 |
0.6 |
0.8 |
0.8 |
|
F |
3.5 |
5 |
5 |
7.8 |
7.8 |
|
ΦD" |
ΦD+0.5max |
|
L" |
L+2max |
Yiyang PengCheng technology development Co., Ltd, was founded in 1988, and is an professional enterprise specialized in development & production of Aluminum Electrolytic capacitors. Our company is engaged in radial electronytic capacitor research and development, production, marketing and service. Adhering the management philosophy of environment protection and energy saving, PengCheng has been one of the most potential manufactures in the aluninum eletrolytic capacitor field in YIYANG, HUNAN.
Our main products including: radial capacitors, general use Aluminum Electrolytic capacitors, LED driver Aluminum Electrolytic capacitors, light capacitors, high capacitance capacitors, Ballast capacitor which are wildely used in battry, electrical household appliances, lighting, etc. RoHS compliant, long life, low leakage and high stability, and wide range of working temperatrue. which make us to be one of the top rank of the Aluminum Electrolytic capacitors suppliers. Through persevering efforts, we have passed ISO9001: 2008, ISO14000: 2001, RoHS certificates. Due to the top quality products, reasonable prices and sincere service, we have also won the trust and support of our customers.
We have got experienced sales and after service system, and products are sold in India and we are planning for developing American, Asia marketing, ect. We develop stable and steady at present and believes credibility and integrity will help make an achievement of future. In the rising economic wave, our company will as just in past stick to the business philosophy -"being stable, credibility and integrity", to develop more new products and improve the quality. Meanwhile, we will improve our after sales system, aims to serve customers with high quality products and service in return for their trust and support.
Rated voltage range: 10V-450 V
Temperature range: Under 25 to 105 deg.
Capacitance: 1-100 UF
Load life: 3000h, 5000h, 8000h, 12000h
Please contact me by email for more details if you are interested.
