Round Panel Light PR93J-DC01-2835T6W
Specifications:
Size:Φ120MM
Model NO: PR93J-DC01-2835T6W
Power:6W
LED type: SMD2835
Input: AC85-265V
Driver:Isolated
Material: Aluminum+ Acryl
Power Factor>0.9
CRI:≥70Ra
Beam angle:120°
Certificate: CE
Warranty:2 years
Benefits&using
1.Energy-saving: Low energy consumption .50% of energy saved than fluorescent lamp
2.Long lifespan:10 times longer than fluorescent lamp
3.Well-being : No UV, No flickering ,no humming ,no buzzing
4.Eco-friendly: no environment pollution
5.Slim and neat design: Ultra thin design
Application: Houses, offices, exhibitions, meeting rooms, hotels, restaurants, schools, factories, hospitals, workshops, storages, etc.Our advantages:
Factory Manufacture Capability |
NO | ITEM | Techinical capabilities |
1 | Materials | Aluminum FR-4 |
2 | layers | 1-36 layers |
3 | Min. core material | 5mil(excluding copper) |
4 | Prepreg type | 7628 2116 1080 3313 |
5 | Max. board size | 520*720mm |
6 | Copper thickness | min. base copper 1/3 OZ |
max. finished copper6OZ |
7 | Min. board thickness | 2- layer 10mil |
4- layer 16mil |
6-layer 24mil |
8-layer 32mil |
10-layer 40mil |
8 | Max. board thickness | 236mil(finished board thickness) |
9 | Min. line width/space | 3mil/3mil HOZ copper base(inner layer) |
10 | Min. hole size | 8mil |
11 | PTH wall thickness | ≥ 1mil |
12 | Hole dia. tolerance | ± 3mil |
13 | Hole dia. tolerance | ± 2mil |
14 | Countersink hole | Min. depth(D)6mil; The Depth of tolerance± 6mil |
16 | Min. solder mask bridge | 3.2mil(HOZ base copper, green) |
17 | Outline tolerance | ± 4mil |
18 | Twist & Bow | ≤ 0.75% |
19 | Peelable mask thickness | ≥ 8mil 1 printing |
20 | Insulation Resistance | > 1012Ω Normal |
21 | Through hole | < 300Ω Normal |
resistance |
22 | Current breakdown | 10A |
23 | Peel strength | 1.4N/mm |
24 | S/M abrasion | > 6H |
25 | Thermal stress | 28 degrees 20Sec |
26 | Test Voltage | 20-300V |
27 | Min. blind/burried via | 8mil |
28 | Surface finish | HAL ENIG IMAG IMSN OSP HAL+G/F ENIG+G/F |
29 | Impedance control | Single ended impedance 50Ω /70Ω ± 10% Normal |
Differential impedance 90Ω /100Ω ± 10% Normal |
