Feature:
1. 36pcs 8W LumiEngin LEDs (R10, G10, B10, W6)
2. Super luminance, comparable to the efficiency of halogen discharge lamps, rich and splendid color.
3. Lower Power consumption
Specification:
Voltage: AC 90-130V/180V-245V, 50/60Hz
Lamp: 36*8W 4IN1 RGBW
Rated Power: 360W
Control Signal: DMX 512/Master-slave/ Auto/Custom/Sound Control
Channels: 14CH(RGBW/A)
Installed with 36 LED Lamps, the power of the products reaches 360W.
The average life time of each LED reaches 100, 000 hours.
Low power consumption.
Super luminance, comparable to the efficiency of halogen discharge lamps, rich and splendid color.
DMX-512 control signal, 14 standard channels.
The housing is made of streamline fashionable PC engineering
Plastic 0f after once casting.
Wide range super tiny smooth scanning, horizontal scanning
Angle reaches 540° , and vertical 270° , the scanning precision
Reaches 8bit and16bit, with smooth and precise positioning,
Additionally, the scanning speed is adjustable.
Infinite RGB color mixed system.
The light beam angle can be 15° , 30° , 45° , 75° , optional.
High speed electronic strobe reaches 1-18 times/second
The channel of general dimmer can control 3 main color
Channels simultaneously.
LCD display.
With the functions of synchro movement and music control.
Meet CE standard, UL standard and GB7000.15--2000 standard.
Size: 380*350*450mm
N/G Weight: 11.0/12.0kg
DMX Channel:
| CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 |
| FUNCTION | PAN | PAN 16bit | Tilt | Tilt 16bit | Dimmer | Strobe | Red | Green | Blue | White | ZOOM | Scan Speed | RGBW macro function | Reset/Auto |
Guangzhou Baiyun Popular Stage Light Equipment Factory is a professional stage lighting manufactory which provides integrated services of research, production, marketing, after-sales inquiry, repair and maintenance. Our equipment are widely used in professional theater, entertainment centers, bars, parks, clubs, nightclubs and multifunctional units of conference halls. Compliant with CE and RoHS standards, our products main involve LED moving head lights, LED PAR lights, controllers, Moving head light, etc.
with strong beliefs in "Practical, Professional & Powerful" to the products, the company provides remarkably superb lighting Performance to all Professional Audience.
Hope we can grow together on the coming days.
