330W Viper Gobo 15r Moving Head Light with Cmy

330w viper gobo 15r moving head light with cmy


Youtube Demo: https://youtu.be/EkwBvKV1Xew



Brighter:
(New 330W Lamp Source Brings Incomparable Pure Brightness)
Small size but stronger:
(Comparable Output Of 1500W Fixtures,but 1/5 Power Consumption and 1/3 size Only 23kg, 41*37*75cm)
Best color system:
(CMY color mixing effect and 6 dichroic colors, YL optic system)
Best gobo system:
(2 gobo wheels: 14 static gobos and 8 rotating replaceable gobos)
Most Funtional:
(Zoom, Iris, Prism, Focus, Frost Filter, Shutter, with full Moving Heads Spot/Wash functions)

TECHNICAL PARAMETERS
POWER SUPPLIE
Input power:AC110-240V 50/60 Hz
LAMP SOURCE
Lamp: Yodn MSD R17 350W,1,500hr, 8000k(Optional Osram Siruis HRI 330W)
Power Consumption: 350W
OPTICS
Lens: Anti-reflective coated lens
YiLong optic system
Output Lux: 10,500lux at 20 meters
COLOR SYSTEM
Colors: Basic color wheel with 6 dichroic mirrors, plus white, two direction rainbow effect.
CMY Variable Color Mixing for Infinite Color Possibilities
GOBO SYSTEM
8 rotating gobos plus open, all gobos can be easily replaceable and gobo indexing
Static gobo wheel with 14 indexing gobos plus open, gobo shaking in different speed
EFFECTS SECTION
Prism and prism rotating , with 16 prism macros
Linear dimmer in precise speed from 0% ~ 100%
Stepless frost, 0%-100% linear change frost
Motorized focus
Iris from 5%~100% with pulse iris effect.
Zoom: 9°~27° linear zoom
Strobe/shutter: High speed shutter, 0-13 Hz or random strobe
CONTROL AND PROGRAMMING
DMX Channels: 3 DMX Modes-21/23/34 Channels DMX
Control: 3-pin&5-pin DMX
Control board with LCD graphic display
BODY
Remote controller lamp's switch function, display light and lamp's using time
Structure: heat-proof plastic+module pressing alloy materials
MOVING BODY
Pan and tilt movement: 8 and 16 bit resolution
For smooth and precise motion
Movement: Pan: 360°/540°optional, Tilt: 270°
Speed of pan/tilt movement adjustable
Scan position memory, auto reposition after unexpected movement
WEIGHT&SIZE
Weight: 23kgs
Dimensions: 409*419*541mm

Channel			Function
21 channel	23 channel	34 channel
CH1	CH1	CH1	Pan
	CH2	CH2	Pan fine
CH2	CH3	CH3	Tilt
	CH4	CH4	Tilt fine
CH3	CH5	CH5	Color wheel
		CH6	Color wheel fine
CH4	CH6	CH7	Cyan
		CH8	Cyan wheel fine
CH5	CH7	CH9	Magenta
		CH10	Magenta wheel fine
CH6	CH8	CH11	Yellow
		CH12	Yellow wheel fine
CH7	CH9	CH13	Rotating gobo wheel
CH8	CH10	CH14	Gobo wheel rotation
		CH15	Gobo wheel fine
CH9	CH11	CH16	Fixed gobo wheel
		CH17	Gobo wheel fine
CH10	CH12	CH18	Prism
CH11	CH13	CH19	Prism rotation
		CH20	Prism fine
CH12	CH14	CH21	Focus
		CH22	Focus fine
CH13	CH15	CH23	Zoom
		CH24	Zoom fine
CH14	CH16	CH25	Strobe
CH15	CH17	CH26	Dimmer
		CH27	Dimmer fine
CH16	CH18	CH28	Iris
		CH29	Iris fine
CH17	CH19	CH30	Frost
CH18	CH20	CH31	Macro function speed
CH19	CH21	CH32	Pan/tilt speed
CH20	CH22	CH33	Macro function
CH21	CH23	CH34	Lamp on/off, reset
