300X600 25W30W LED Panel Light with 3 Years Warranty
| Price: |
US $ 23.75/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
100/Piece |
| Pay Type: |
T/T,D/P,Paypal,Money Gram,Western Union |
300X600 25W30W LED Panel Light with 3 Years Warranty
Features
1.High intensity SMD, Luminous efficiency more than 110lm / W
2.Integrated waterproof design, safe and reliable attractive appearance
3.High efficiency cooling, the relative temperature rise is less than 15°C
4.Ultra-thin, the thickness is less than 3.5mm.
5.meet the requirement of IP40
6.Lifetime is up to 50, 000 hours
High-strength and high quality steel for lamp body,imported anodize aluminium for lamp reflector.Super energy-saving led light source;Original innovated patent circuit,power consumption is 1/3 of fluorescent tube;Smooth appearance,easy installation,long life
1 . Applications
- Office , production workshop , factory , metro station , waiting room , ticket lobby , supermarket , store , warehouse , indoor lighting , city lighting projects and so on .
2 . LED panel light Features
- The light source adopts the low power LED of SMD3528 , imported high brightness semiconductor chips.
- The profiles in aluminum tensile die casting ensures the efficiency of heat emission, guaranteeing the light a long life span.
- We uesd the imported light guide plate and spread board , effectively improve the light transmittance , and it can make sure the luminous flux , controlling the light inside of a useful area . It improves the efficiency of light uniformity and utilization .
- New high efficiency constant current driver . Wide range of input voltage : AC100-240V.
- No delay start. No waiting . No noise .
- No electrical wave , conforming to CE .
- Environment friendly and no air pollution . It's no heat radiation . There is no ill to our eyes and skin . The floodlights do not have lead , hydrargyrum and any other contamination .
3. led panel light main specifications ( T=25 °C ) :
More inforamtion, pls contact Fiona Chu
| ITEM | DESCRIPTION |
| Input Voltage | AC100-240V 47-63 Hz |
| Power | 25w/30w |
| LED Efficiency | 80-90Lm/W |
| Initial Flux (600x600 50w) | >5000Lm ( Cool white ) >4600Lm ( Natural White ) >4100Lm ( Cool White ) |
| Power factor | >0.9 |
| Color | Warm White / Natural White / Cool White / Red / Green / Blue / Yellow |
| Color Temperature | 2700-3300K ( Warm White ) 4000-5000K ( Natural White ) 5300-7000K ( Cool White ) |
Center Illuminance
(600x600,50w) | 1.5M: 709Lux 3.0M: 493Lux 6.0M: 170Lux |
| Beam Angle | 160 ° |
| Life Time | >50,000 Hours |
| Operating Temperature | -20°C to +40°C |
| Storage Temperature | -30°C to +55°C |
| Connect Wire | Brown : L Blue :N Yellow/Green :G |
| Certifications | CE, RoHS,ISO9001-2008 |
| IP Code | IP40 |
4 . Safety Notice for Using
- Please always use the light out of its package.
- Any maintenance should be performed by trained professionals only.
- Caution. The packaging contains small parts that may be swallowed by children.
- Try to avoid looking directly in the LED beam-especially for extended periods of time.
5 . Maintenance
- Prior to cleaning the light, make sure it has been disconnected from the power supply.
- Use a dry or slightly moistened cloth for cleaning.
6 . LED panel light Installation
- When laying the cables, make sure that the cables and plugs are not subjected to any tensile or twisting forces. Fit the cable tension relieving mechanisms to the connection points of the surface-mounted lights. Do not kink cables.
- Proceed by connecting the wiring cables to the luminaries. Usually, the brown(or black) wire is the live wire, connect it with the terminal marked "L". The blue wire is Naughty wire, connect it with the terminal marked "N".
- Used only the LED driver included, and do not connect the surface-mounted lights to other loads.
- Do not remove the name plate of the power supply and driver of the light.
| Prod Model: |
300x600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Sizes: |
All Range |
| Light Source: |
LED |
| Appearance: |
Square |
| Type: |
Hanging |
| Emitting Color: |
White |
| Certification: |
VDE |
| Housing Material: |
Acrylic |
| Base Material: |
ABS |
| Voltage: |
85V-265V |
| Dimmable: |
With Dimmable |
| Beam Angle: |
120 |
