Specifications
36w 60x60 led panel light jiangjing
1.High Power&High lumen
2.High CRI&Dimmable
3.3 years warranty
4.CE&RoHS
LED Panel Light
Product Features:
1. LED brand : Epistar
2. Beam Angle: 120°-180°
3. CRI: Ra80
4. High PF>90
5. With internal power supply,Driver input voltageAC85-265V,50/60Hz
Technical parameters for all of our panel lights:
Jiangjing Lighting specialises in high performance LED flat panels. Our LED panels are direct replacements for ceiling fluorescents and grid panels, same size of ceiling. All LED light panels are available in dimmable and in either cool white, day white or warm white.
| Item No. | Watt | Voltage | Dimmable | LED Source | Dim. | Net Weight |
| (W) | (V) | (pcs) | (mm) | (Kg) |
| JJ-PL10W-0303-P | 10W | AC85-265V | No | SMD 2835 40 LEDs | 300*300 | 0.93 kg |
| JJ-PL10W-0303-D | AC110V/220V | Yes |
| JJ-PL20W-0603-P | 20W | AC85-265V | No | SMD 2835 50 LEDs | 600*300 | 2.50 kg |
| JJ-PL20W-0603-D | AC110V/220V | Yes |
| JJ-PL40W-0606-P | 40W | AC85-265V | No | SMD 2835 100 LEDs | 600*600 | 4.50 kg |
| JJ-PL40W-0606-D | AC110V/220V | Yes |
| JJ-PL40W-1203-P | 40W | AC85-265V | No | SMD 2835 100 LEDs | 1200*300 | 4.50 kg |
| JJ-PL40W-1203-D | AC110V/220V | Yes |
| JJ-PL80W-1206-P | 80W | AC85-265V | No | SMD 2835 200 LEDs | 1200*600 | 8.50 kg |
| JJ-PL80W-1206-D | AC110V/220V | / |
Applications:
The LED panel light is ideal replacement for the traditional downlights,it has wide range of application such as:
1. Jewelry counter lighting
2. Commercial lighting
3. Restaurant, hotel
4. Artwork lighting
5. Display case
6. Amusement park
7. Home and office lighting.
Shenzhen Jiangjing Lighting Co.,Ltd. is a professional high-tech manufacturing enterprise, engage in researching&development, Engineering, manufacturing, marketing and service of LED illuminations.
The first-class automatic SMT, DIP and reflow production line.
1. About Product:
A. Certificates: CE, ROHS FCC SAA
B. Warranty: 3 years.
2. About Factory:
A. Certificate: ISO9001.
B. Experience: Over 4 years OEM & ODM experience on specialized LED Light.
C. Excellent service on before-sale, on-sale and after-sale:
Quick Response, all your questions will be answered within 24 hours. Our motto is: "Quality first, Customer utmost".
We have professional sales team, who is not only a replier but also a problem solver, we always give customers the most feasible marketing suggestions according to their own market mode.
D. Monthly production capacity:
up to 300,000 sets on a LED Linear Pendat Light
3. About Market:
Our products are widely accepted in North America,European countries etc.
LED Panel Light-UL/DLC
Shenzhen Jiangjing Lighting Co., Ltd is a manufacturing enterprise with national high technology, we devotes to researching and developing new products with advanced technology, and has rich experience in the field of commercial lighting and special biological application lighting. "Being strict with quality, producing top-quality products", adhering to this faith, all designs of our productsabide by Electric Security Standard of Europe and America. Through scientific matching and design for lamp, light source and electrical equipment, Jiangjing Lighting do the best to improve the lighting effect, reduce energy intensity and increase product's service life, to providing customers with the best lighting solutions, as well as supporting environmental protection and comprehensive energy saving.
Jiangjing Lighting own full sets of advanced professional manufacturing equipments and inspection equipment, together with high level of technology talented person, a variety of LED lamps produced here pass the international CE, RoHS, FCC certifications. With good reputation, we establish friendly relationship of cooperation with many different companies from North America, Europe, Southeast Asia and other countries, and become their long-term trusted partner step by step.
In the future, Jiangjing Lighting will promote the development and application of advanced lighting technology, carry out our faith and promise with expert spirit! Jiangjing is always ready to provice customers with the best service! !
