Features:
1.with a bight osram lamp.
2.powerul beam effect with output of 70000 lumen at 10m.
3.it offers 13 colors and 14 gobos,allowing you to change the shape of the beam and create an array of spectacular mid-air effect, with single direction rotation rainbow effect.
4.3 layer optic glass lens and 8 facet roatable prism.
5.with it's light weight and modest footprint,sharpy is small enough to be used in many place---on trusses,at live and on stage ,TV events and in showrooms and conference rooms,etc.
Technology Parametric:
Voltage: 110V/240V AC, 50/60 Hz
Power Consumption: 150W
Display: Colourfull led display
Lamp: philips 2r lamp
Ballast: Electronics ballast
Lumen output: 70000 LM/ 10 meter
Color Temperature: 8000 K
Lens: 3-layer optic glass lens
Prism: 8 prism rotation
Gobo: Gobo wheel with 14 gobos
Colors: Color wheel with 13 colors, single rotation rainbow effect
DMX channel: 16 CH or 20CH
Control mode: Master-slave ,DMX mode,Auto mode
Head movement: Pan 540° (16 bit),Tilt 270° (16 bit) electric correction
With Pan/Tilt fine function Auto correction function
Focus: Double automatic focusing
Dimmer: Independent dimmer channel, 0-100% linear dimmer
Strobe: Independent strobe channel, 1-13 times/s, speed adjustable
Lamp DMX ON/OFF: Lamp DMX on/ off, ignited by inverter, protect and lengthen the lifetime of the bulb
LCD display
High temperature protection
Body size: 34X23X42cm
Cartoon size: 40X30X50cm
Gross weight: 11KG
channel chart:
| CH | DMX Channel |
| 16 | 20 |
| 1 | COLOUR WHEEL - | COLOUR WHEEL - |
| 2 | STOP/STOBE | STOP/STOBE |
| 3 | DIMMER | DIMMER |
| 4 | STATIC GOBO CHANGE - | STATIC GOBO CHANGE - |
| 5 | PRISM INSERTION - | PRISM INSERTION - |
| 6 | PRISM ROTATION | PRISM ROTATION |
| 7 | EFFECTS MOVEMENT | EFFECTS MOVEMENT |
| 8 | FROST | FROST |
| 9 | FOCUS | FOCUS |
| 10 | PAN - | PAN - |
| 11 | PAN - FINE | PAN -FINE |
| 12 | TILT - | TILT - |
| 13 | TILT - FINE | TILT - FINE |
| 14 | MACRO FUNCTION | MACRO FUNCTION |
| 15 | RESET - | RESET - |
| 16 | LAMP CONTROL | LAMP CONTROL |
| 17 | NO FUNCTION | Pan-Tilt Speed |
| 18 | NO FUNCTION | COLOR WHEEL SPEED |
| 19 | NO FUNCTION | Dimmer-Prism -Frost Speed |
| 20 | NO FUNCTION | Static Gobo speed |
Trade terms:
| Price Term | exw price |
| Payment terms | T/T,Paypal,Western union |
| Shipping Way | 1.By express(DHL,Fedex,Ups,EMS) |
| 2.By air |
| 3.By sea |
| Sample time | 1-3 workdays |
| Production time | general 5-10 days,depend on your order quantity |
| Packing | 1.Standard Carton |
| 2.Flightcase |
| Warranty | 1 years |
| After-Sell server | 1.If there is some problems with the product,please describe it and sent thenecessary picture or video to us for analyzing. |
| 2.Then we will guide you how to fix it and provide free accessories if needed. |
| 3.1year quality guarantee at least, and we will provide free parts for replacement if any problem belong to us during the period(Delivery cost paid by customer);1 year later, we can provide spare parts for replacement based on certain charge. |
