Technicial Parameter :
Power supply: AC90-245V, 50/60Hz
Ballast: Electromagnetic Ballast or Electronic Ballast
Color Temperature:8500K
Average Lamp Life:2000H
Power Consumption: 150W
Lamp: OSRAM 120W (DMX on/ off)
Lumen output: 70000 LM/ 10 meter
Color Temperature: 8000 K
Lens: 3-layer optic glass lens
Prism: 8 prism rotation
Gobo: Gobo wheel with 14 gobos
Colors: color wheel with 13 colors, single rotation rainbow effect
DMX channel: 16/20 CH
Control: master-slave mode
DMX mode: auto mode
Head movement: Pan 540°(16 bit) electric correction
Tilt 270°(16 bit) electric correction
with auto-correction function
Focus: Double automatic focusing
Dimmer: independent dimmer channel, 0-100% linear dimmer
Strobe: independent strobe channel, 1-13 times/s, speed adjustable
Lamp DMX ON/OFF: lamp DMX on/ off, ignited by inverter, protect and lengthen the lifetime of the bulb .
P.S : this item is with same program to the Clay Sharpy's , it is a kind of mini Clay Sharpy , with same DMX CH , just smaller in size.
.
CH | DMX Channel |
| 16 | 20 |
| 1 | COLOUR WHEEL - | COLOUR WHEEL - |
| 2 | STOP/STOBE | STOP/STOBE |
| 3 | DIMMER | DIMMER |
| 4 | STATIC GOBO CHANGE - | STATIC GOBO CHANGE - |
| 5 | PRISM INSERTION - | PRISM INSERTION - |
| 6 | PRISM ROTATION | PRISM ROTATION |
| 7 | EFFECTS MOVEMENT | EFFECTS MOVEMENT |
| 8 | FROST | FROST |
| 9 | FOCUS | FOCUS |
| 10 | PAN - | PAN - |
| 11 | PAN - FINE | PAN -FINE |
| 12 | TILT - | TILT - |
| 13 | TILT - FINE | TILT - FINE |
| 14 | MACRO FUNCTION | MACRO FUNCTION |
| 15 | RESET - | RESET - |
| 16 | LAMP CONTROL | LAMP CONTROL |
| 17 | NO FUNCTION | Pan-Tilt Speed |
| 18 | NO FUNCTION | COLOR WHEEL SPEED |
| 19 | NO FUNCTION | Dimmer-Prism -Frost Speed |
| 20 | NO FUNCTION | Static Gobo speed |
