SKILL SPECIFICTIONS:
Power: 110V-240V AC, 50/60HZ~
Fuse: T 10A 250W
Power consumption: 300W
DMX-control-channels
Display and operating instructions
DMX 16channels instruction
Address code
Control
Technique parameter
Power supply
Lamp
Color-wheel
Gobo-wheel
8-facet rotating prism
Shutter
Focus
Dimmer/shutter/strobe
Fans
Motors
RIGGING
Stands directly on the floor
2 truss orientation
Cam locks system with adapter plate and 2 Omega holders
Safety chain/cord attachment point
TEMPERATURES
Maximum ambient temperature ta: 40º C
Maximum housing temperature tb: (steady state)80º C
| channel | Function explanation |
| 1CH Pan | 0-255 | 540° |
| 2CH Tilt | 0-255 | 270° |
| 3CH 16 bit pan | 0-255 | 3.6° |
| 4CH 16 bit tilt | 0-255 | 3.6° |
| 5CH Pan./ Tilt. speed | 0-255 | Fast - slow |
| 6CH Soft | 0-255 | Wash Effect |
| 7CH Strobe | 0-255 | 0-2 Light off
3-49 Light on
50-239 Strobe(slow-- Fast)
240-250 Light off
251-255 Light on |
| 8CH Dimmer | 0-255 | 0-20 Light off
21-255 Dimmer(0-100%) |
| 9CH Color Wheel | 0-255 | 0-7 No function
8-127 Change the color
128-266 Color flow
|
| 10CH Color Wheel Effect | 0-255 | 255 9CH 1/2 Effect |
| 11CH Gobo Wheel | 0-255 | 0-7 No function
8-127 Change the gobo
128-255 gobo flow |
| 12CH Gobo shake | 0-255 | 0 No function
1-191 Gobo shake(slow-- Fast)
192-255 No function |
| 13CH Focus | 0-255 | Focus |
| 14CH Prism | 0-255 | 8- Prism |
| 15CH prism rotating | 0-255 | prism rotating |
| 16CH lamp(on/off)/ Rest | 0-255
| 0 No function
105 lamp off
205 lamp on
255 Rest |
