Product Features
1. High brightness 5630 SMD LED as light source;
2. Diffuser plate imported from Japan, with soft and comfortable light effect;
3. Adopted integrated design, the shell optimized efficiency of heat dissipation.
4. Lamp body adopt surface baking varnish disposal, looks elegant.
5. MCPET Reflective sheeting (from Japan Furukawa Electric) is used; It improves more than 25% of lamp effect.
6. External power supply is fixed on lamp body, it's safer and easier for installation & packing.
7. Beam angle: >140°
8. Life span: ≥ 50, 000 hours, Warranty;
9. Utility model patent.
Comparison with Normal Down Light
§ Structure optimization, strength and heat dissipation is improved significantly;
§ The whole luminous efficiency flux nearly 30% higher, on average 90lm/W.
§ No dark area, No Flickering, Shining smoothly.
§ Light and grace, easy to install and remove.
§ The light body is thin, easy for installation
Introduction and Advantages of MCPET
1. It takes 10 years for Japan Furukawa Electric Co, Ltd to develop the MCPET reflector, whose reflection rate reaches 99% which ranking the NO. 1 in this industry to solve the glare lighting and Uneven lighting problems. With the high Micro-foamed and great spreading ability, it can improve the illumination and viewing angle design & application greatly, the raising rate can reach to 40%~60%.
2. Excellent flections characteristic (reflection rate 99%. Spreading reflection rate: 96%. Secular reflectance: 3%)
3. Light in weight and good resistance to the drop impulse, high temperature resistance (can remain the intact under the temperature 160 degree)
4. The waste material can be recycled by using PET method. The material is non-toxic and has a very smooth surface etc
5. In secondary process aspect, it can be moldered by cropping, stamping, curving, heating etc.
|
Power |
Size |
CCT |
Lumen |
Working Voltage |
CRI |
LED Type |
LED Quantity |
Lighting |
|
Angle |
|
10W |
D140*48mm |
White
(5500-6500K) |
950lm |
AC100-240V |
75 |
5630 SMD |
24 |
140° |
|
Neutral White(4000-4500K) |
920lm |
AC100-240V |
73 |
5630 SMD |
24 |
140° |
|
Warm White(2800-3200K) |
900lm |
AC100-240V |
70 |
5630 SMD |
24 |
140° |
|
20W |
D190*54mm |
White
(5500-6500K) |
1950lm |
AC100-240V |
75 |
5630 SMD |
48 |
140° |
|
Neutral White(4000-4500K) |
1890lm |
AC100-240V |
73 |
5630 SMD |
48 |
140° |
|
Warm White(2800-3200K) |
1850lm |
AC100-240V |
70 |
5630 SMD |
48 |
140° |
|
28W |
D228*60mm |
White
(5500-6500K) |
2750lm |
AC100-240V |
75 |
5630 SMD |
72 |
140° |
|
Neutral White(4000-4500K) |
2680lm |
AC100-240V |
73 |
5630 SMD |
72 |
140° |
|
Warm White(2800-3200K) |
2600lm |
AC100-240V |
70 |
5630 SMD |
72 |
140° |
Founded in 2006, Torshare Ltd. Is one of the biggest manufacturers of LED-related products in China, which is specialized in researching, developing, engineering and marketing of LED products. Occupied by 12, 000 square meters, 200-250 staff, due to good quality and perfect after sales service, Torshare Ltd is enjoying high reputation. It is located in the center of Chinese LED, Shenzhen Shiyan Town, where is about 30 minutes drive from Hong Kong, and 15 minutes drive from Shenzhen Airport, we welcome any group or person to visit our factory.
Our products cover a wide range, such as LED Tube Light, LED downlight, LED spotlight, LED panel light, High power series, LED Sign, Strips, Modules, OEM etc. We are specially proud of our OEM business since we have many professional engineers who have worked in the field of LED for over 10 years. Highly trained workers make sure our products are in 100% good quality. Professional sales follow up with our customers at any time. According to our advantages, we have witnessed our rapid development. Right now, our annual export sales topped $13.5 million in 2010, a 60% increase from the previous year.
We have one set of strict Quality Inspection System. Our 15 QC staff monitor the entire production process to ensure our product quality meets your requirements. We use advanced temperature testers, luminance testers and photoelectric instruments to conduct strict testing such as voltage withstand, shock proof and salt spray tests. All our operations are ISO 9001: 2008-certified. Our qualification rate is above 99.5%. All our products comply with CE standard and the RoHS Directive.
Under the common effort of all staff; We fully believe we will do better and better in the following days.
