Description:
It adopts high brightness quality LED as luminous body with low-voltage constant current river, low power consumption, long lifespan, reliability and safety.The housing, which is elegant and stylish,is made if high-quality anti-UV and heat resistant plastic. Built-in large area of heat dissipation Aluminum plate ensures stable working of LED, and controls light attenuation effectively.Perfect optical design ensures soft and even liht. Instant lighting, no flickering, no glaring. Free of lead, mercury and other harmful substances. This product is widely used in shopping mall, hotel, restaurant and etc.
1.Plastic coated aluminium profile for good heat dissipation.
2.Thermal conductive plastic housing make sure safe light.
3.V-0 flame rating.
4.Triac dimmable version for option.
5.Working temperature: -20°C ~ 40°C.
6.Driver built-in.
7.Warranty: 3 years.
8. Packing Info:Ctn size: 83.5*50.5*26.5cm, 30pcs/ctn,Gross weight:20.5KGS/ctn.
Model | HDL-P10225-CM |
Current | 150mA |
Watt | 20W |
Power Factor | 0.9 |
Working Temperature | -20ºC~-40ºC |
VAC | 110-277V/220V |
Input Current (A) | 0.15 |
CRI(Ra) | 80 |
Hours | 40000hrs |
Color Temperature | 3000K(WW)/4000K(NW)/6000K(CW) |
LUM | 1500/1600/1600 |
Protection Rate | Lighting fixture surface IP44 |
Size(mm) | 240*32 |
Cutout | 220mm-230mm |
Dirver | Inner built |
Pcs per carton | 30pcs |
Carton Size | 83.5*50.5*26.5cm |
Gross Weight | 20.5kg/ctn |
Notes:
1. Only qualified electrician is allowed to do the installation, maintence and inspection for safety concern.
2.It is dangerous for non-professional operator.
3.Ceiling Recessed installation only.
4.Do not install the product in high temperature or humid place.
5.Storage conditions: room temperature dry environment.
Installation:
1. Turn off the power.
2. Drill a suitable mounting hole on ceiling according to size requirement of different item.
3. Connect the commercial power wire wih the reserved power supply outlet. Pinch both springs, then push light into installation hole. Make sure the light fixed well.
4. Re-check everything is well-connected, then turn on the power.
