TECHNICAL PARAMETERS
POWER SUPPLIE
Input power:AC100-240V 50/60 Hz
LED:19PCS 12W high power RGBW LED
DMX channel:14/53 channels
Control mode:DMX512/Master-Slave/Auto run
Display:Blue blue ground LCD display
Beam angle:6-50degree
WEIGHT&SIZE
G.W: 9.2 KG
Packing size:324.8*188*395.4mm
MENU FUNCTION
DMX Address
001~512
Run Mode
DMX 14 Channel
DMX 53 Channel
Auto Run
Sound Control
Master Auto Run
Master Sound Control
Slave run
Manual Control
PAN
PAN =000
PAN-FINE
PAN-Fine =000
TILT
TILT =000
TILT-FINE
TILT-Fine =000
Move Speed
Move Speed =000
Dimmer
Dimmer =000
Strobe
Strobe =000
Red
Red =000
Green
Green =000
Blue
Blue =000
White
White =000
Effect Motor
Effect Motor =000
Language Setting
English
Advanced Setup
Pan Reverse
Tilt Reverse
Display Reverse
Reset Motor
Factory Set
Home Position Set
Password
Code =018
PAN
PAN =000
TILT
TILT =000
Red
Red =000
Green
Green =000
Blue
Blue =000
White
White =000
Effect Motor
Effect Motor =000
System State
On Time
Accumulative Time
Current Run Mode
Temperature
Software Version
Guangzhou Mintforbers Lighting Equipment Co., Ltd. is a high-tech enterprise specializing in R&D, design and sales of stage lighting, architectural lighting and and other professional stage lighting products. Our company was established in the year 2007 and we have our owner sales office in Shenzhen City. The light production base located in the Baiyun district, we own professional production troop engaging in R&D, production and sales.
Our major products include LED light, Moving head light, Scanner, Laser light, Professional audio and so on. Also we supply OEM service for customers from all parts of the world.
