TECHNICAL INFO
Power supply: AC110V-250V
Frequency: 50-60Hz
Power consumption: 350W
Profile LED Source: 1PCS 180W Ultra Bright LED
Wash LED Source: 12*9W tri-color RGB LEDs
Lamp life: 6-10 ten thousand hrs
Pan movement: 540 degrees, 8bit/16bit adjustable, electronic correction
Tilt movement: 270 degrees, 8bit/16bit adjustable, electronic correction
Pan/Tilt resolution: 8-16 bit
Dimmer: 0-100% electronic dimmer
Strobe: 0 ~ 20 times / sec, adjustable
Adjusting focus: Electric linear focus 15° , 18°
One Rotating gobo wheel: 7 interchangeable gobos + Open
One Color wheel: 7 colors+ white & rainbow-flow effect
Three-prism: Can rotated adjust the speed, can change the direction
Working temperature: -10º C-45º C maximum
Control channels: 31/17/13 CH
Control mode: DMX512, master/slave, auto, custom, sound active
Cooling: Low noise fan
Operation menu: LCD screen display
Packing size: 650*430*490mm
N. W: 16kg
G. W: 18kg
13CH |
17CH |
31CH |
Function |
Channel Value |
Function |
CH1 |
CH1 |
CH1 |
Pan |
0-255 |
0-540° |
CH2 |
CH2 |
CH2 |
Tilt |
0-255 |
0-270° |
|
|
CH3 |
Pan Fine Tilt |
0-255 |
Pan Fine |
|
|
CH4 |
Tilt Fine |
0-255 |
Tilt Fine |
CH3 |
CH3 |
CH5 |
X, Y speed Adjustment |
0-255 |
From fast to slow |
CH4 |
CH4 |
CH6 |
Profile Dimmer |
0-255 |
From dark to bright |
CH5 |
CH5 |
CH7 |
Profile Strobe |
0-7
8-250
251-255 |
Turn on
Strobe from fast to slow
Turn off |
CH6 |
CH6 |
CH8 |
Color: 7colors+ open |
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-191
192-255 |
Open
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color CW fast > slow
Color CCW fast > slow |
CH7
|
CH7
CH7 |
CH9
|
7 Static Gobos + Open |
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-191
192-255 |
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Wheel CW Fast > slow
Wheel CCW Fast >slow |
CH8 |
CH8 |
CH10 |
Gobo Indexing Rotating |
0-15
16-95
96-115
116-135
136-155
156-175
176-215
116-255
|
Stop
Gobo Fine 0-360
Gobo Rotating 0-90
Gobo Rotating 0-180
Gobo Rotating 0-360
Gobo Rotating 0-720
Gobo self-rotating CW from slow to fast
Gobo self-rotating CCW rotating from slow to fast |
CH9 |
CH9 |
CH11 |
Focus |
0-255 |
focus from near to far |
CH10 |
CH10 |
CH12 |
Prism |
0-63
64-255 |
Open
Prism In |
CH11 |
CH11 |
CH13 |
Prism Rotation |
0-15
16-136
137-255 |
Stop
Rotate CW slow > fast
Rotate CCW slow > fast |
CH12 |
CH12 |
CH14 |
For mirror |
0-63
64-255 |
Open
Fog mirror in |
|
CH13 |
CH15 |
Global Red |
0-255 |
From dark to bright |
|
CH14 |
CH16 |
Global Green |
0-255 |
From dark to bright |
|
CH15 |
CH17 |
Global Blue |
0-255 |
From dark to bright |
|
CH16 |
CH18 |
Global Strobe |
0-255 |
From slow to fast |
|
|
CH19 |
RGB LED1 |
0-255 |
From slow to fast |
|
|
CH20 |
RGB LED2 |
0-255 |
From dark to bright |
|
|
CH21 |
RGB LED3 |
0-255 |
From dark to bright |
|
|
CH22 |
RGB LED4 |
0-255 |
From dark to bright |
|
|
CH23 |
RGB LED5 |
0-255 |
From dark to bright |
|
|
CH24 |
RGB LED6 |
0-255 |
From dark to bright |
|
|
CH25 |
RGB LED7 |
0-255 |
From dark to bright |
|
|
CH26 |
RGB LED8 |
0-255 |
From dark to bright |
|
|
CH27 |
RGB LED9 |
0-255 |
From dark to bright |
|
|
CH28 |
RGB LED10 |
0-255 |
From dark to bright |
|
|
CH29 |
RGB LED11 |
0-255 |
From dark to bright |
|
|
CH30 |
RGB LED12 |
0-255 |
From dark to bright |
C
CCH13 |
CH17 |
CH31 |
Built-In Program |
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-143
144-159
160-175
176-190
191-255 |
Single Control
LED Chase
LED Run
LED Jump
LED Edacity
LED
Image 1
Image 2
Image 3
Image 4
Image 5
Image 6
Total Progrm |
