E-SOURCES Advantages
1) We can do PCB, PCBA, led pcb&pcba,led down light, led panel light, led ceiling light, led bulb light, led tuble light, and others. We can also offer ODM, OEM and EMS one stop service, can ensure high quality and low price.
2) Excellent Service, our experienced engineers and advanced equipments can control the producing, inspection and after service to satisfy our customers need, and our dedicate sales team can provide 24 hours service.
9/12/15/18w slim led panel lights led panels led downlights
Product Specification:
Light Source: Use High power with high quality and brightness.
Body: Use the aluminum section of low rth and high-thermal conductivity, quick heat dissipation with high efficiency, the streamline design let our products elegant appearance.
Lampshade: Made by professional optical material, light transmittance over 84%.
Grading: Adopt particular light distribution, the spot is very uniform and soften the light.
Long Service Life: Normally, LED light can be used for 50,000 hours.
No Flicker: Using off-line PWM switch constant-current supply driver, high color rendering, safe and no flicker.
Factory Manufacture Capability |
NO | ITEM | Techinical capabilities |
1 | Materials | Aluminum FR-4 |
2 | layers | 1-36 layers |
3 | Min. core material | 5mil(excluding copper) |
4 | Prepreg type | 7628 2116 1080 3313 |
5 | Max. board size | 520*720mm |
6 | Copper thickness | min. base copper 1/3 OZ |
max. finished copper6OZ |
7 | Min. board thickness | 2- layer 10mil |
4- layer 16mil |
6-layer 24mil |
8-layer 32mil |
10-layer 40mil |
8 | Max. board thickness | 236mil(finished board thickness) |
9 | Min. line width/space | 3mil/3mil HOZ copper base(inner layer) |
10 | Min. hole size | 8mil |
11 | PTH wall thickness | ≥ 1mil |
12 | Hole dia. tolerance | ± 3mil |
13 | Hole dia. tolerance | ± 2mil |
14 | Countersink hole | Min. depth(D)6mil; The Depth of tolerance± 6mil |
16 | Min. solder mask bridge | 3.2mil(HOZ base copper, green) |
17 | Outline tolerance | ± 4mil |
18 | Twist & Bow | ≤ 0.75% |
19 | Peelable mask thickness | ≥ 8mil 1 printing |
20 | Insulation Resistance | > 1012Ω Normal |
21 | Through hole | < 300Ω Normal |
resistance |
22 | Current breakdown | 10A |
23 | Peel strength | 1.4N/mm |
24 | S/M abrasion | > 6H |
25 | Thermal stress | 28 degrees 20Sec |
26 | Test Voltage | 20-300V |
27 | Min. blind/burried via | 8mil |
28 | Surface finish | HAL ENIG IMAG IMSN OSP HAL+G/F ENIG+G/F |
29 | Impedance control | Single ended impedance 50Ω /70Ω ± 10% Normal |
Differential impedance 90Ω /100Ω ± 10% Normal |
30 | Max. aspect ratio | 12:01 |
FAQ
Q1: What is your products range?
We provide PCBA for IT, communication, tablet PCs, smart cards, financial equipments, auto electronics, GPS modules.led light for led panel light, led tube light, led bulb light ,led down light, and etc. We can do OEM,ODM.
Q2:What is your payment term ?
T/T or L/C at sight.and It ' s negotiable
Q3:What is you trade term?
FOB Guangzhou/Shenzhen port.
Q4:Do your pay for import taxes and duty?
No, they are not included. Clients should pay for them.
Q5:How long do you need to make samples? And how about the lead time?
About 15-20 days for samples, and about 45 days bulk production after get your payment
Q6: How do you make sure product quality?
We have 3D SPI, AOI,and we do ICT, Electronic test, Visual inspection, Functional test.
