15W RGB3in1 Ceiling LED Down Light with CE/RoHS

15W RGB3in1 Ceiling Led Down light with CE/RoHS

RGB Ceiling light, RGB COB downlight, rgb led ceiling light, rgb ceiling lamp, ceiling downlight, Downlight, Led Downlight, 1*3w ceiling light, 5-24v led ceiling lamp


RGBW led Ceiling light series adopts high brightness, low decay, high efficiency 3W high power LED as light source. Aluminum alloy shell. Such as 3 W High power White LED +3W 3IN1 RGB led, 5x3W RGB: 3PCS 3 IN 1 RGB LED +2pcs White LED, 9X3W RGB: 6PCS 3 IN 1 RGB LED +3pcs White led. There are different lens available. It has energy-saving, environment protection, long lifespan, anti-shock and anti-vibration features. It's new generation green product. It can fit various temperature differences between indoor and outdoor.

Specifications

5-24V RGB LED ceiling lamp;
(Taiwan EPISTAR or epileds LED)
*Supply Voltage: 5-24V DC
*Dimensions: ø 50*H28mm
*Total Power: 3.6W
*Color: 3in1 RGB
*LED QTY: 1PCS (3IN1) LED
*Brightness: R: 40LM G: 70LM B: 25LM
*Beam angle: 45/60
*Packing size: 55*25*25CM(40PCS)
*G. W: 7kg
*. Approval: CE & RoHS, FCC
*. Warranty: 2 year
*Using conventional RGB controller, voltage 5-24VDC

Main Applications

It's widely used for commercial lighting and home lighting places such as, shopping mall, jewelry store, hotel, boutique, amusement hall, showroom etc.

Ordinary features

1. High quality and high power LED light source;
2. Projection angle adjustable from 1-90 degree, projection distance: 0.5-20m;
3. Standard optical beam angle is 45 degree, (45° /60° Available)
4. To generic RGBW LED ribbon controller,
We are supporting the company's controller Five standard DMX channel: Red, green, blue, strobe, dimming the total, general brightness and general dimming, support DMX512 console
5.256 grade brightness, R, G, B color can realize about 16, 770, 000 color output;
6. Standard 3-pins male and female DMX signal connector, one input and one output

Drawing

Part Number	Specifications
SU-1x3W-RGB-DC (3IN1)	5-24V RGB LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage: 5-24V DC *Dimensions: ø50*H28mm      *Total Power: 3.6W *Color :3in1 RGB *LED QTY:1PCS (3IN1) LED *Brightness: R:40LM  G:70LM B:25LM     *Beam angle: 45/60 *Packing size: 55*25*25CM(40PCS) *G.W:7kg *.Approval:CE & RoHS,FCC *Using conventional RGB controller, voltage 5-24VDC
SU-3x3W-RGB-DC (3IN1 RGB led)	12-24V RGB LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:12-24V DC *Dimensions: ø90*H55mm      *Total Power: 10.8W *Color :3in1 RGB *LED QTY:3PCS (3IN1) LED *Brightness: R:120LM  G:210LM B:75LM     *Beam angle: 45/60 *Packing size: 42*22*42CM(40PCS) *G.W:13kg *.Approval:CE & RoHS,FCC *Using conventional RGB controller, voltage 12-24VDC
SU-5x3W-RGB-DC (3IN1 RGB led)	24V RGB LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:24V DC *Dimensions: ø105*H78mm      *Total Power: 18W *Color :3in1 RGB *LED QTY:5PCS (3IN1) LED *Brightness: R:200LM  G:350LM B:125LM     * Beam angle: 45/60 *Packing size: 42*22*42CM(40PCS) *G.W:16kg *.Approval:CE & RoHS,FCC *Using conventional RGB controller, voltage 24VDC
SU-5x3W-RGBW-DC (3IN1 RGB+White led)	12-24V RGBW LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:12-24V DC *Dimensions: ø105*H78mm      *Total Power: 18W *Color :3in1 RGBx3W+2PCSX3W White *LED QTY:5PCS(3in1 RGBx3W+2PCSX3W White) *Brightness: R:120LM  G:210LM B:75LM    W:350lm * Beam angle: 45/60 *Packing size: 42*22*42CM(40PCS) *G.W:16kg *.Approval:CE & RoHS,FCC *Using conventional RGB controller, voltage 24VDC
SU-9x3W-RGBW-DC (3IN1 RGB+White led)	24V RGBW LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:24V DC *Dimensions: ø148*H98mm      *Total Power: 27W *Color :3in1 RGB+ White *LED QTY:9PCS(6PCS 3in1 RGBx3W+3PCSX3W White) *Brightness: R:160LM  G:420LM B:150LM    W:540lm * Beam angle: 45/60 *Packing size: 42*22*42CM(24PCS) *G.W:19.8kg *.Approval:CE & RoHS,FCC *Using conventional RGBW controller, voltage 24VDC
SU-1x8W-RGBW-DC           (4 IN1 LED)	8W RGBW LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:12-24V DC *Dimensions:ø68*H55mm     *Total Power: 8W *Color : RGBW or RGBWW *LED QTY: Taiwan EPISTAR or epileds LED 1R 1G 1B 1WX2W *Lumens: R:60LM G:90LM B:35LM W:160LM * Beam angle: 60 *Packing size: 55X25X25cm  50PCS 7.5kg *.Approval:CE & RoHS,FCC *Using conventional RGBW controller, voltage 24VDC
SU-3x8W-RGBW-DC           (4 IN1 LED)	24W RGBW LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage:12-24V DC *Dimensions: ø90*H75mm       *Total Power: 24W *Color : RGBW or RGBWW *LED QTY:  Taiwan EPISTAR or epileds LED 3R 3G 3B 3WX2W *Lumens: R:180LM G:270LM B:90LM W:420LM * Beam angle: 15/30 45/60 /80 *Packing size: 55X25X25cm 20PCS 9.5kg *.Approval:CE & RoHS,FCC *.Warranty:2 year *Using conventional RGBW controller, voltage 24VDC
SU-5x8W-RGBW-DC           (4 IN1 LED)	40W RGBW LED ceiling lamp; (Taiwan EPISTAR or epileds LED)                                           *Supply Voltage: 24V DC *Dimensions:  ø105*H78mm       *Total Power: 40W *Color : RGBW or RGBWW *LED QTY:  Taiwan EPISTAR or epileds LED 5R 5G 5B 5WX2W *Lumens: R:300LM G:450LM B:150LM W:700LM * Beam angle: 15/3045/60/80 *Packing size: 55X25X25cm 20PCS 12kg *.Approval:CE & RoHS,FCC *.Warranty:2 year *Using conventional RGBW controller, voltage 24VDC
