technical parameter:
Power Supply: AC120v-240V 50/60hz
Power Consumption: 330W
Lamp: Osram 330W, 1, 500hr, 8000k(Optional YODN R17 350W)
Out put Lux: 1.0500lux at 20 meters
DMX Channels: 3 DMX Modes-21/23/34 Channels DMX
Control: 3-pin&5-pin DMX
CMY: CMY Color Mixing System
Lense: Anti-reflective coated lense
Color: 6 colors+open
Fix Gobo: 14 fixed gobos+open
Rotation gobo: 8 rotation goboes+open
Focus: Motorized Focus
Zoom: 9° To 27° Variable Zoom Beam Angle
Prism: 3 face prism and prism rotation and 16 prism macro
Dimmer: Mechanical Dimmer 0-100%
Strobe: Variable speed Shutter / Strobe
Iris: Motorized Iris
Pan/Tilt: 540° For pan, 270° For Tilt
Fixtures: Remote controller lamp's switch function, display light and lamp's using time
Structure: Heat-proof plastic+module pressing alloy materials
IP rate: IP20
Weight: 23kgs
Dimensions: 409*419*541mm
| CHANNEL | CHANNEL MODE |
| 16CH | 20CH |
| 1 | COLOUR WHEEL | COLOUR WHEEL |
| 2 | STOP/STROBE | STOP/STROBE |
| 3 | DIMMER | DIMMER |
| 4 | STATIC GOBO CHANGE | STATIC GOBO CHANGE |
| 5 | PRISM INSERTION | PRISM INSERTION |
| 6 | PRISM ROTATION | PRISM ROTATION |
| 7 | EFFECTS MOVEMENT | EFFECTS MOVEMENT |
| 8 | FROST | FROST |
| 9 | FOCUS | FOCUS |
| 10 | PAN | PAN |
| 11 | PAN FINE | PAN FINE |
| 12 | TILT | TILT |
| 13 | TILT FINE | TILT FINE |
| 14 | PAN/TILT SPEED | PAN/TILT MOVE BLACK |
| 15 | RESET | RESET |
| 16 | LAMP CONTROL | LAMP CONTROL |
| 17 |
| PAN-TILT TIME |
| 18 |
| COLOUR TIME |
| 19 |
| DIMMER-PRISM-FROST TIME |
| 20 |
| GOBO TIME |
| CH MODE | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 |
| 16CH | COLOUR WHEEL | STOP/ STROBE | DIMMER | STATIC GOBO CHANGE | PRISM INSERTION | PRISM ROTATION | EFFECTS MOVEMENT | FROST | FOCUS | PAN | PAN FINE | TILT | TILT FINE | FUNCTION (UNUSED) | RESET | LAMP CONTROL |
|
|
|
|
| 20CH | PAN-TILT TIME | COLOUR TIME | DIMMER-PRISM-FROST TIME | GOBO TIME |
Guangzhou Baiyun Popular Stage Light Equipment Factory is a professional stage lighting manufactory which provides integrated services of research, production, marketing, after-sales inquiry, repair and maintenance. Our equipment are widely used in professional theater, entertainment centers, bars, parks, clubs, nightclubs and multifunctional units of conference halls. Compliant with CE and RoHS standards, our products main involve LED moving head lights, LED PAR lights, controllers, Moving head light, etc.
with strong beliefs in "Practical, Professional & Powerful" to the products, the company provides remarkably superb lighting Performance to all Professional Audience.
Hope we can grow together on the coming days.
