Structure and Power supply
Sturdy die-cast aluminum body conceived for long-time durability and demanding applications
Frontal tempered glass panel
Internal Protection: IP67 (IP) - IP54 (TZ)
Pressure and temperature balance through GORE membrane vents
Power (shuko) and data (xlr-3p) adapter cables included
Double hanging bracket suitable for safe hanging and for floor positioning
Power unit: 100-240V 50/60Hz
Power output to link more units in a chain: Up to 24 fixtures at 230V
Max power consumption: 52W
Weight: 4, 8 kg
Dimensions (WxHxD): 245x205x245 mm
Light source and optics
14 x 3W high-efficiency CREE RGB/FC LED
Lumen: 950
Lux@2m: 2350@2m
Energy-saving LED employed, with more vivid colors and lower power consumption than traditional lamps
Color synthesis: Tricolor color mixing (>16 million colors) for a limitless color range
White temperature presets: 3200K~10000K
Installed optics: 16°
Beam angle: 17°
Field angle: 32°
LED average life span: >50'000h
BY LIGHTING LIMITED is a high-tech integrated enterprise engaging in design, manufacture and sales of indoor and outdoor LED lights. Our products are widely used in stage, disco, advertising and architectural industry etc.
Since the establishment of our company, we have been devoted to supply high quality products and excellent after sales device to our customers. In the course of our growth, we have been striving to enhance continually our design, R&D and manufacturing capabillities. We pride ourselves on exporting our products to Europe, Asia, Middle East etc.
The high-caliber management team and skilled R&D engineers are regarded as our valuable assets. In addition to this, wide-spread sales network and excellent after sales service are very helpful for our success in this competitive market. With the goal of customer first in mind, we are pursuing a policy of sustainable development, dedicated to supplying high quality LED lights and excellent after service.
