Feature:
1.With it's compact size and light weight, this light is an ideal lighting effect for any mobile entertainer, small nightclub, bar or lounge and for Bowling and entertainment centers.
2.This fixture features a bright 12-Watt LED engine and 12 exciting built-in light shows in a very compact mobile case.
3.This pocket sized, flat mirrored Scanner has a 14-degrees beam angle, precision stepper motors for speed and accuracy.
4.The fast mirror speed means that it is great for high energy music, and provides a great compliment to Moving Head effects for pure lighting excitement.
Technical Parameter:
Power consumption: 33W
Voltage : AC 100 - 240V, 50/60Hz
LED Source: 12W RGBW LED
Life time: Rated at approximately 50,000 hrs
Channel:9 /16DMX channels
Control mode: DMX, Sound Active & Internal Show control modes
Beam Angle: 14 degrees
Dimming: 0% - 100%
X/Y mirror movement:X axial 175°,Y axial 30°
Stepper motors with micro stepping
5 selectable Dim Curves (Standard, Stage, TV, Architectural & Theatre)
Shutter: Pulse effect; random strobe slow to fast
Display: LED digital display
Dimensions (LxWxH): 275 x 130 x 170mm
N.W: 1.6 kgs
DMX Channel:
| 9CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| Function | X motor | Y motor | Dimmer | Red Dimmer | Green Dimmer | Blue Dimmer | White Dimmer | Strobe | Macro functio |
|
|
|
|
|
|
|
|
|
|
| 16CH | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
|
| Function | X motor | X motor fine | Y motor | Y motor fine | Y motor speed | Y motor effect | X,Y motor effect | Macro functio |
|
| 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
|
| Dimmer | Strobe | Red Dimmer | Green Dimmer | Blue Dimmer | White Dimmer | color outo run | color outo run speed |
|
