Light Source: LED
Item Type: Street Lights
LED Light Source: Bridgelux, Epistar
Input Voltage(V): AC: 100-240V
Lamp Power(W): 200
Lamp Luminous Flux(lm): 19000
Lamp Luminous Efficiency(lm/w): 95
CRI (Ra>): 75
Color Temperature(CCT): 3000-6500K
Working Temperature(ºC): -40 - +50
Working Lifetime(Hour): 50000
Lamp Body Material: Aluminum Alloy
IP Rating: IP65
Certification: CE, RoHS
Warranty(Year): 3
Place of Origin: Zhejiang, China (Mainland)
Brand Name:
Model Number:
Maximum Current:: AC 2.06A -120V, 1.03A -240V
Driver Brand: Mean Well
Driver Efficiency: > 90%
Power Factor (PF): > 0.95
Operating Humidity: 10% to 90%
Heat Radiator: Anodized Aluminum
Lens: PC
Fixture Dimension: 992 x442 x211 mm /39.1 x17.4 x8.3 inches
Fixture Weight: 18.0 kg /39.7 lbs
Aperture Diameter: 60 mm /2.4 inches
Datasheet
| Electrical Specifications |
| Nominal Wattage | 200W |
| Nominal Voltage | AC 100-240V, 50/60Hz |
| Maximum Current | AC 2.06A-120V, 1.03A-240V |
| Optimal Operating Temperature | - 40 ºC to 50 ºC |
| Operating Humidity | 10% to 90% |
| Power Factor (PF) | >0.95 |
| Driver Efficiency | >90% |
| Photometric Specifications |
| Correlated Color Temperature (CCT) | 3000-3500K, 4000-4500K, 5000-5500K, 6000-6500K |
| Lumen Output (3000-4500K) | 18000 lm ( +/- 5% ) |
| Lumen Output (5000-6500K) | 19000 lm ( +/- 5% ) |
| Color Rendering Index (CRI) | Ra≥75 |
| Mechanical Specifications |
| IP Rating | IP65 |
| Lifetime | 50000 hours |
| Housing | Die-casting Aluminum |
| Heat Raditor | Anodized Aluminum |
| Lens | PC |
| Fixture Dimension | 992 x 442 x 211 mm / 39.1 x 17.4 x 8.3 inches |
| Fixture Weight | 18 kg / 39.7 lbs |
| Aperture Diameter | Φ60 mm / Φ2.4 inches |
| Packing Informations |
| Packing Type | 1 unit / ctn |
| Packing Dimension | 1040 x 490 x 260 mm / 40.9 x 19.3 x 10.2 inches |
| Packing Weight | 21 kg / 46.3 lbs |
Features
1 | No UV | 12 | Significant energy savings |
| 2 | Long life | 13 | Wide input: 100 - 240V AC |
| 3 | Waterproof | 14 | Stable and efficient LED driver |
| 4 | Instant on/off | 15 | Significantly less generated heat |
| 5 | Mercury free | 16 | Resistant to shock and vibration |
| 6 | Maintenance free | 17 | Optimal heat sinking performance |
| 7 | Improved visibility | 18 | LED's maintain flux up to 100 lm/W |
| 8 | Ease of installation | 19 | Temperature compensation technology |
| 9 | Copper free aluminum | 20 | Exclusive appearance design with patents |
| 10 | Superior optical design | 21 | High quality and brightness LED light source |
| 11 | More than twice the average life of metal halide and high pressure sodium |
