technical parameter:
Voltage: AC110-240V 50-60Hz
Power Consumption: 150W 220V, 50Hz
Light Source: 2R bulb
Color Temperature: 8000K
Ballast: Electronics ballast
OPTICS:
3-layer HQ optics glass lens
Focus: Optical focus
Channels: 13 channel
Color Wheel:
One with 13colors+open
With adjustable rotation, speed adjustable
With double direction rotation and rainbow effect
Fixed Gobo Wheel:
With 14 static gobos+open
With double direction rotation
With sharking effect With adjustable rotating speed
Prism:
8-facet rotating prism
Strobe:
Mechanical Strobe 1-12 F. P. S
With adjustable strobe speed
Movement:
Pan0-540º /Tilt 0-270º
With Pan/Tilt fine function Auto correction function
LCD display
High temperature protection
Body size: 34x23x42cm
Cartoon size: 40x30x50cm
Gross weight: 11KG
CH | DMX Channel |
| 16 | 20 |
| 1 | COLOUR WHEEL - | COLOUR WHEEL - |
| 2 | STOP/STOBE | STOP/STOBE |
| 3 | DIMMER | DIMMER |
| 4 | STATIC GOBO CHANGE - | STATIC GOBO CHANGE - |
| 5 | PRISM INSERTION - | PRISM INSERTION - |
| 6 | PRISM ROTATION | PRISM ROTATION |
| 7 | EFFECTS MOVEMENT | EFFECTS MOVEMENT |
| 8 | FROST | FROST |
| 9 | FOCUS | FOCUS |
| 10 | PAN - | PAN - |
| 11 | PAN - FINE | PAN -FINE |
| 12 | TILT - | TILT - |
| 13 | TILT - FINE | TILT - FINE |
| 14 | MACRO FUNCTION | MACRO FUNCTION |
| 15 | RESET - | RESET - |
| 16 | LAMP CONTROL | LAMP CONTROL |
| 17 | NO FUNCTION | Pan-Tilt Speed |
| 18 | NO FUNCTION | COLOR WHEEL SPEED |
| 19 | NO FUNCTION | Dimmer-Prism -Frost Speed |
| 20 | NO FUNCTION | Static Gobo speed |
