Feature:
1. High brightness 2R lamp
2. 3-layer optic glass lens, It makes the outputed beam looks brighter and better
3. 8 facet rotation prism
4. Facotry supply, good quality and compective price
Technology Parametric:
Voltage: AC110-240V 50-60Hz
Power Consumption: 150W 220V, 50Hz
Light Source: 2R bulb
Color Temperature: 8000K
Ballast: Electronics ballast
OPTICS:
3-layer HQ optics glass lens
Focus: Optical focus
Channels: 13 channel
Color Wheel:
One with 13colors+open
With adjustable rotation, speed adjustable
With double direction rotation and rainbow effect
Fixed Gobo Wheel:
With 14 static gobos+open
With double direction rotation
With sharking effect With adjustable rotating speed
Prism:
8-facet rotating prism
Strobe:
Mechanical Strobe 1-12 F. P. S
With adjustable strobe speed
Movement:
Pan0-540º /Tilt 0-270º
With Pan/Tilt fine function Auto correction function
LCD display
High temperature protection
Body size: 34X23X42cm
Cartoon size: 40X30X50cm
Gross weight: 11KG
DMX Channel:
| Voltage | AC90-240V, 50-60Hz |
| Ballast | Electronic ballast |
| Light Source | 120W |
| Power consumption | 150W |
| Color Temp | 8500K |
| Lifespan | 2000hrs |
| Output lux | 7000lux @ 10 meter |
| Lens | 3-layer glass optical lens |
| Color | 13 color + blank, single rotation rainbow effect |
| Gobo | 14 gobo + blank |
| Pan/Tilt | X axis 540°, Y axis 270°, 16bit electric correction |
| Channel | 16/20CH |
| Control mode | DMX512, Sound and master-slave modes |
| Focus | Double automatic focusing |
| Dimmer | Independent dimmer channel, 0-100% linear adjustment |
| Strobe | Independent strobe channel, 1-13times/s, adjustable speed |
| Fixture | DMX on/off, lamp on/off, ignited by inverter, protect and lengthen the lifespan of the lamp |
| N.G/W | 5.5/6.5kgs |
| Packing Size | 32*25*46mm |
| IP rate | IP20 |
| Certification | CE, RoHS |
