1206 LED Strip Light

LED Strip Light:
1: Black flexible PCB board LED strip light is 12PCS 1206 SMD LED as luminous body.
2: Looks like star shinning when lit up.

1, This LED strip light adopt a kind super flexible black PCB board as base and 12PCS super bright 1206 SMD LEDs as its luminous body. Viewing angle is 120° . These LEDs are evenly arranged on the PCB board.
2, Small connectors connect each other. When lit up, it looks like the stars shinning against the clear night sky.
3, The LEDs are made by ourself. The luminous body is of very high intensity, large viewing angle, good quality and stability.
4, Excellent waterproof craft makes the product elegant. The waterproof rate can achieve IP64
5, Availabel Color: Red, Yellow, Blue, Green, White, Warm White, Pink etc.
6, It can keep flexible and easy-shaping under the working temperature: -20° C to + 60° C. It characters as easy for installation, stable, and energy-saving. It is an ideal lighting decoration product for both indoor and outdoor, such as guide sign, edge decoration, stair decoration, car decoration, etc.

Features:
1) Waterproof flexible LED strip use 1206 SMD LED as the lighting source on flexible PCB, can be bended to the contour of any products with self adhesive tape back.
2) Every 3 LEDs in a unit. Each unit 50mm.

3) LED Viewing angle 120 degree.
4) Available in various single colors, such as red, blue, yellow, green and white.
Red 625nm, 150lm, green 525nm 480lm; Blue 470nm 109lm; Yellow 590nm 148lm, white x: 0.28, y=0.29, 560lm; Warm white x=0.42, y=0.4, 545lm.
5) We suggest that max length for the light strip is 5 meter. If longer than 5 meter, the LED on the end of the strip may not have the same luminous intensity as the ones at the front.
6) Work voltage: 12V DC
7) Power dissipation: 24W.
8) L 4960mm* W 8mm* H 2.5mm
9) Application: Path&contour marking

Elegant interior decoration
Backlighting for larger size ad-signs
Landscape outlines
Signal lighting, etc.
