Input voltage: AC220~240V, 50/60Hz;
Rated power: 1500W;
Lamp source: HMI 1200W short arc;
Color temperature: 5, 600k;
Lifetime: 750 hours;
Color system: 1 color wheel with 5 colors plus white;
Color effect: Strong CMY color washing can make single color rainbow, single color movement and flowing movement effect in adjustment speed;
Focus: Electric linear focusing;
Zoom: Stepless zooming with angle 12° ~17° ;
Dimmer: Mechanical dimmer with half color and full color effect;
Strobe: 1-10 flashes per second;
Head movement: 450° Pan, 270° Tilt;
Control: DMX512 signal, 3pcs pins, 16CH, 12pcs motors;
Display: Liquid-crystal display in English;
Up to CE standard and GB7000.15-2000 standard;
Each light has cut light function to make point projection special effect;
Material: Aluminum alloy and heat resistance plastic;
G. W.: 55KG;
Dimension: 630*600*890mm (carton); 600*460*890mm (flycase 1 pcs);
|
Channel |
Function |
|
CH1 |
Strobe |
|
CH2 |
Dimmer |
|
CH3 |
Pan |
|
CH4 |
Tilt |
|
CH5 |
Pan fine |
|
CH6 |
Tilt fine |
|
CH7 |
Pan/tilt speed |
|
CH8 |
K |
|
CH9 |
Zoom |
|
CH10 |
Color box |
|
CH11 |
o |
|
CH12 |
M |
|
CH13 |
Y |
|
CH14 |
CMY color |
|
CH15 |
CMY speed |
|
CH16 |
Reset |
Uplight Stage Equipment (Guangzhou) Co., Ltd. is a high-tech company, which is engaged in R&D, manufacturing and marketing of stage equipments. The main products include moving lighting, LED stage equipments, follow spot, laser light, gobo light, etc.
We own a professional R&D team, who has 10 years experience in stage lighting. Our sales team can provide best service by engineers and technical staff members' supporting. We passed the ISO9001: 2000 quality management system standard as well. There are numerous domestic projects we have been undertaken, was praised by all the customers.
To become the leading stage lighting supplier on a global basis. We view our customers as the most important element in our business, strive to exceed the customer's expectation.
