12CH LED Mover/LED Moving Head/108 PCS 3W LEDs RGBW/DMX512 Stage Lighting
Key Features:
* 108 x 3W high quality LED's, Edison LED chip, Red 24PCS, Green 28PCS, Blue 28PCS, White 28PCS
* White + Red + Green + Blue + linear CTO
* Lens 15 degree(Optional: 8 degree, 25 degree, 30 degree, 45 degree, 60 degree)
* 0~100% linearly adjustable dimmer
* Strobe: 1~25 times/s
* Pan 540 degree, Tilt 270 degree with auto position correction, speed adjustable.
* IP 20 waterproof rating
* Friendly LCD display
* 12CH international standard DMX channels
* DMX signal control / master-slave control / sound control
Products Details
Standard Accessories:
G clamps, 2 PCS; Signal cable, 1 PC; Holder, 1 PC;
Technical Data
Power Supply: 90~260V AC, 50/60Hz (power supply)
Power Consumption: 400W@220V
LED Source:
3W Edison LED
108 LED's (Red 24PCS, Green 28PCS, Blue 28PCS, White 28PCS)
Manufacturers Rated LED Life: 50, 000 hours
Colour System:
White + Red + Green + Blue
Linearly colour temperature correction
Effect:
Dimmer: 0~100% linearly adjustable
Strobe: 1~25 times/s
Lens Angle:
15 degree(Optional: 8 degree, 25 degree, 30 degree, 45 degree, 60 degree)
Control and Programming:
Control: DMX512, 3-pin interface, Self-test mode, DMX signal control, Master /Slave mode
Channels: 12CH international standard DMX channels
HEAD MOVEMENT:
Pan 540 degree, Tilt 270 degree with auto position correction
Physical Features:
Ambient Working Temperature: -20 degree~40 degree
Housing: Plastic + aluminum, IP20
Weight: 9Kg
Package:
1. Carton with protected foam inside. Packed quantity: 1PC
2.4in1 flightcase
| Channel | function |
| Ch 1 | Pan |
| Ch 2 | Tilt |
| Ch 3 | RGBW luminance adjustment |
| Ch 4 | Strobe |
| Ch 5 | RED |
| Ch 6 | GREEN |
| Ch 7 | BLUE |
| Ch 8 | WHITE |
| Ch 9 | Scanning luminance |
| Ch 10 | RGB Macro function |
| Ch 11 | Auto function |
| Ch 12 | Reset function |
