10° -60° 1500W spot moving head light(OA-3800 spot)
-Voltage: AC 220V± 10% 50-60Hz
-Power: 1750W
-30 channels controlling
-DMX 512 Signal receiving
-OSR HTI 1500W/D7/60 lamp, cold light glass reflector
-LCD intellective display panel
-CMY with DOT and pectination structure, and stepless color mixing system,
CMY macro function inside, with gradual color temperature correction function.
-One color wheel, six colors plus white, with rainbow and half color effect.
-Colors flow bidirectionally. Color filters changeable.
-Two oriented and rotatable gobo wheels, each has five changeable glass gobos or metal gobos, each gobo with shaking effect.
-One effect wheel, linear lambency glass, rotating beam shaper and three-facet prism.
-One animation gobo filter, and the gobo filters are replaceable, can create flouting clouds, raining, stream, rising flame effect etc.
-0-100% linear mechanical dimmer with strobe as 0.5~14 flash/s, inside with strobe macro function.
-Electric Iris, 10~100% linear adjustment, inside with iris macro function.
-Linear focusing 10 degree~60 degree(w/o wide-angle lens),
-Focusing: 0.5m to infinity.
-540 degree pan with 8 or 16 bit resolution.
-270 degree tilt with 8 or 16 bit resolution
-Automatic Pan and Tilt repositioning by photoelectric repositioning system accidentally knocked out of place.
-Superheat protection: Fan system automatically adjusts wind speed by circle temperature.
-Power saving function: When the switch or all the CMY filters shuttered, the lamp consumption can be reduced 50% automatically extending the lamp life and improving stability.
-Electronic ballast, power factor is 0.98, supports saving mode. With a special function: Lamp control 2 position electronic adjustment: 750W, 1500W, wide range of working voltage.
-Intelligent menu design: Runs shortcut selection. Pan/Tilt three position optional: High, Middle, Low.
All functions can manually directly been adjusted through the menu panel, and save as initialization state, also with an automatic alarm inside, which are convenient and easy testing and maintain.
International Protection: IP 20
Size: 500x405x745mm
N. W: 37.50kgs
Up to CE standard and GB7000.217-2008 Standard.
|
CH01 |
Dimmer |
|
CH02 |
Strobe |
|
CH03 |
Color wheel |
|
CH04 |
Cyan |
|
CH05 |
Magenta |
|
CH06 |
Yellow |
|
CH07 |
Color marco |
|
CH08 |
Gobo1 |
|
CH09 |
Gobo 1 rotation |
|
CH10 |
Rotating gobo1 index fine(LSB) |
|
CH11 |
Gobo 2 |
|
CH12 |
Gobo 2 rotation |
|
CH13 |
Rotating gobo2 index fine(LSB) |
|
CH14 |
Animation wheel position |
|
CH15 |
Animation wheel rotation |
|
CH16 |
Prism |
|
CH17 |
Prism rotation |
|
CH18 |
Iris |
|
CH19 |
Focus |
|
CH20 |
Zoom |
|
CH21 |
Pan coarse |
|
CH22 |
Pan fine |
|
CH23 |
Tilt coarse |
|
CH24 |
Tilt fine |
|
CH25 |
Pan/Tilt speed |
|
CH26 |
Motor speed1 |
|
CH27 |
Motor speed 2 |
|
CH28 |
Control |
|
CH29 |
Power adjustment |
|
CH30 |
Gobo macro |
Guangzhou Omarte Lighting Co., Ltd. is one of the fastest developing enterprise, which is prefessional in stage moving light 1500W&1200W, LED stage lighting and 7KW giant color outdoor searchlight and controller. We experience in theste category of products for more than 6 year. After year by year efforts, we stand more and more stable in the morket and have been recognized as the father of high power lighting manufacturer. We also have strict quality control and strong technical developing system, ISO9001: 2000 reputation, as well as good sales services. At the time, we are making effort to develop new products to meet the home market and the international market. We continuously strive to improve the quality of products and perfect our sales services.
At present, Omart lighting is in the leading positon of the industry with advanced technology, superior quality and stable performance. Excellent performance has been shown by our products in large popular art shows, stadiums and TV halls etc. Thus, well reputation by exports has been flooding to Omarte lighting.
