Special design of end-cap
Design of removable and rotatable end-cap provides quick replacement of inner-transformer by pressing the switch on the end caps easily. Different from other tubes which fixing end-cap by glue, this new tube designed by our R&D, and it enables customers open the tube to replace inner-transformer if the transformer fails after some years' usage. And lighting angle can be adjustable.
Perfect design to avoid LED failure in series
Our company invested much in R&D and researched a new technology to make all LEDs in the tube work independently. Namely, if one LED fails, no impact to other LED. However, most LED tube in the market designed with at least 7 LEDs per series. 1 LED doesn't work, all other 6LEDs or more not work. Lumen of the whole tube will drop much.
Top quality PC cover
For our tube, both transparent and milky covers are available. For milky cover, when lighten the tube, LEDs are invisible. Namely, light effect is very even and same as traditional fluorescent light. We realized 100% perfect replacement.
Great Lighting source
The chip of LED is of high quality and bigger size, 10*23 chip, which is from Epistar in Taiwan. It can resist higher anti-static and distribute more brightness.
Low light attenuation
Esp. The white light is adopting new technology, less than 3% in 1000hrs, however, the traditional attenuation of white color at least 30%.
Super quality inner transformer
We have our own researching and development team to focus on LED driver. The driver we researched for our tube is double isolated and high PF>93%.
More durable & robust
It can light up to 10 years, comes with 3 years guarantee time.
High safety performance.
We have double isolation from our transformer. What is more, our tubes are UL(E344777& E344777), CE(TUV) approved and RoHS compliant. with the range of CE, we have passed through EMC and LVD test, so you can apply the tube for your projects freely.
Tube package
High quality cylindrical package and pin protection avoids shipping damage. Pls refer more information on last page about package information.
|
Length |
Part No. |
Color |
Color Temp. |
Lumen |
Power |
CRI(Typical) |
Viewing Angle |
|
60cm |
T001/T8-N8PW-60 |
Pure white |
6000-6500K |
810lm |
8W |
78 |
120° |
|
T001/T8-N8NW-60 |
Neutral White |
4000-4500K |
750lm |
8W |
78 |
120° |
|
T001/T8-N8WW-60 |
Warm white |
3000-3500K |
680lm |
8W |
75 |
120° |
|
T002/T8-N8PW-60 |
Pure white |
6000-6500K |
1015 lm |
10W |
78 |
120° |
|
T002/T8-N8NW-60 |
Neutral White |
4000-4500K |
950lm |
10W |
78 |
120° |
|
T002/T8-N8WW-60 |
Warm white |
3000-3500K |
890lm |
10W |
75 |
120° |
|
120cm |
T004/T8-N8PW-120 |
Pure white |
6000-6500K |
1650lm |
16W |
78 |
120° |
|
T004/T8-N8NW-120 |
Neutral White |
4000-4500K |
1600lm |
16W |
78 |
120° |
|
T004/T8-N8WW-120 |
Warm white |
3000-3500K |
1450 m |
16W |
75 |
120° |
|
T005/T8-N8PW-120 |
Pure white |
6000-6500K |
2050lm |
20W |
78 |
120° |
|
T005/T8-N8NW-120 |
Neutral White |
4000-4500K |
1980lm |
20W |
78 |
120° |
|
T005/T8-N8WW-120 |
Warm white |
3000-3500K |
1800lm |
20W |
75 |
120° |
|
150cm |
T006/T8-N8PW-150 |
Pure white |
6000-6500K |
1875lm |
18W |
78 |
120° |
|
T006/T8-N8NW-150 |
Neutral White |
3000-3500K |
1815lm |
18W |
75 |
120° |
|
T006/T8-N8WW-150 |
Warm white |
3000-3500K |
1750lm |
18W |
75 |
120° |
|
T007/T8-N8PW-150 |
Pure white |
6000-6500K |
2250lm |
22W |
78 |
120° |
|
T007/T8-N8NW-150 |
Neutral White |
4000-4500K |
2170lm |
22W |
78 |
120° |
|
T007/T8-N8WW-150 |
Warm white |
3000-3500K |
1900lm |
22W |
75 |
120° |
Founded in 2006, Torshare Ltd. Is one of the biggest manufacturers of LED-related products in China, which is specialized in researching, developing, engineering and marketing of LED products. Occupied by 12, 000 square meters, 200-250 staff, due to good quality and perfect after sales service, Torshare Ltd is enjoying high reputation. It is located in the center of Chinese LED, Shenzhen Shiyan Town, where is about 30 minutes drive from Hong Kong, and 15 minutes drive from Shenzhen Airport, we welcome any group or person to visit our factory.
Our products cover a wide range, such as LED Tube Light, LED downlight, LED spotlight, LED panel light, High power series, LED Sign, Strips, Modules, OEM etc. We are specially proud of our OEM business since we have many professional engineers who have worked in the field of LED for over 10 years. Highly trained workers make sure our products are in 100% good quality. Professional sales follow up with our customers at any time. According to our advantages, we have witnessed our rapid development. Right now, our annual export sales topped $13.5 million in 2010, a 60% increase from the previous year.
We have one set of strict Quality Inspection System. Our 15 QC staff monitor the entire production process to ensure our product quality meets your requirements. We use advanced temperature testers, luminance testers and photoelectric instruments to conduct strict testing such as voltage withstand, shock proof and salt spray tests. All our operations are ISO 9001: 2008-certified. Our qualification rate is above 99.5%. All our products comply with CE standard and the RoHS Directive.
Under the common effort of all staff; We fully believe we will do better and better in the following days.
