Stage LED Electronic Billboard Indoor LED Display P10

Stage LED Electronic Billboard Indoor LED Display P10
Price: US $ 300-450/Square Meter
Trade Terms: FOB,CIF,EXW
Min Order: 1/Square Meter
Pay Type: T/T,Western Union
Product Description

P10 Full Color indoor LED Display (320*160mm LED Display)

A. High brightness with low power comsumption.
B. Stabel lifespan.
C. Flatness gap between cabinets.
D. Standarlization frame in case update.
E. Easy installation charactristic.

Shenzhen Mountain A-Li is specialized in LED display, LED display screen, indoor led display, outdoor led display, advertising led display and LED billboard. We offer good products and customized solution that meet the need of our customers.

The LED application products research and develop by Mountain A-Li has full range and structure diversification, its products cover LED full color display for indoor and outdoor, LED advertisement display, LED stage display, LED irregular-shape display, LED display for taxi, LED sports display, LED traffic information display, which has been dominated in demestic and international market in this industry.

Indoor LED Display Feature

1. Mountain A-Li full color outdoor led display has high brightness and adjustable contrast. This model has a good lighting accordance and has no mosaic.

2. Mountain A-Li indoor LED display has larging view angle, it also has a better viewing effect for text, graphic and video ects, any LED in each pixel can be respectively repaired.

3. Computer VGA indoor display with real-time synchronization output, and applies to all types of Internet connections with the media to transmit real-time information.

4. Mountain A-Li led screens have brightness strong, static driving scan mode, larger power-driven.

5. In the visual distance of the full color LED sign surface direct sunlight, display clearly visible.

6. A gray 4096 super Grey scale control and Y unlined correct function, color display more than 16.7 trillion, close to natural color.

7. Mountain A-Li led display screen has automatic brightness adjustment function, in different light conditions can attain the best effectives.

8. Mountain A-Li full color led display can widely used in stadium, bank, school, restaurant, shopping centre, station, goverment, entertainment centres and so on.

9. Mountain A-Li is a professional LED stage display, LED Outdoor video wall, Wedding LED display, The stage LED electronic screen, LED large screen full color display, advertising led display, outdoor led display, indoor led display manufacturer.

Our service

1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Mountain A-Li
6. Mountain A-Li can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.

Trade Terms

1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, Mainland China
5. Warranty time: 7years
6. Delivery time: 3-12 working days


Application Case:
It is Widely use for shopping malls, entertainment venues, schools, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station weiting area, indoor stadium, and a cariety of public facilities and so on.
The specifications of modules
ItemsParameter
Product Model P10 Full Color Led Module
Module size320mm*160mm
 Pixel pitch 10mm
 Pixel density  10000dots/m2
Pixel configuration1R1G1B
 Module resolution32dots(W)*16dots
Module maximum power consumption15W
 Module Thickness13CM
Module Weight0.369kg
Driving methodConstant Current Driving
Scanning method1/8 scan
InterfaceHUB75A
Brightness  ≥1800cd/m2
The specifications of cabinets
Cabinet size960mm*960mm
 Module quantity18pcs
 Power supply5V/40A  5V/60A
Cabinet resolution  96*96dots
 Optimal viewing distance10M ~ 50M
Optimal viewing angle160°(W) 120°(H)
 RHWorking temperature(Work :-20 degree~ +50 degree )
  System operating humility10%-95%
The specifications of power supplier
Operating VoltageAC220V±10%
 Average power consumption80W/H
 Maximum power consumption≤240W/m2
 Electric current ≤20mA(single LED)
The specifications of control card
Control Panels Pentium4 or above
Operating system WIN98/2000/NT/XP
Control modelSynchronization with PC
The specifications of the main technical parameters
 Driving deviceConstant Current Driving
 Refresh rate≥2200HZ
 Grey scaleRGB Each 256, can display 16.7M colors)
MTBF≥9000hours
Power switchAutomatic Switch
Display Mode800*600/1024*768/1280*900
Prod Model: indoor p10 led display
Markets: South America,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe
Module Size: 320mm*160mm
Scan Method: 1/8 Scan
Brightness: >1800CD/M2
Optimal Viewing Angle: 160°(W) 120°(H)
Refresh Rate: >2200Hz
Display Type: LED Video Display
Tube Chip Color: Full Color
Display Function: Video Display
Scanning Mode: 1/8 Scan
Application: Shopping Guide
Pixel Configuration: 1R,1G,1B
Pixel Pitch: 10mm
Certification: FCC
Pixel Density: 10,000 dots / m²
System Operating Platform: WIN XP
IP Rating: IP31
Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.

Features:

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
