Home LED Light Products Spcial Indoor Soft P10 LED Advrtising Display with CE RoHS UL

Spcial Indoor Soft P10 LED Advrtising Display with CE RoHS UL

Spcial Indoor Soft P10 LED Advrtising Display with CE RoHS UL
Price: US $ 600-1150/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: T/T

p10 led display flexiable moudle with high performance
SpecificationP10
Item 1 ---LED Chip
Brand Epistar ,Opto , Cree , Nichia
Country of OriginTaiwan. United States. Japan
Span life ≥ 100,000 Hrs
Item 2--- Modules
Pixel Pitch PH 10
LED configurationSMD 3528
LED Composition1R1G1B
Modules size 320  (L)  mm  *   160  (H) mm
Driving IC MBI 5024/5041
Driving Method Constant Current / (1/8 scan)
Item 3--- Cabinet
Screen size 640mm(W)*640mm(H)*80mm(D)
Cabinet Material Iron
Installation Method Fix / Hanging / Rental
Cabinet weight 70Kg
Item 4--- Display screen
Brightness ≥  850cd/m2
Viewing AngleH140° / V140°
Refresh Rate ≥1920 Hz
Fresh Requency 60fps
Input Voltage AC220V/50Hz or AC110V/60Hz
Power Consumption Max.:280 W/m2    Average:100W/m2
Front and Back protective Grade IP43
Signal  Output HDMI DVI VGA RGBHV PbPr (HDTV)
Signal Connection Video  TB SDI
Controlling System Linsn/ Colorlight / Nova/ DB Start
Operating System Windows98/me/2000/NT/XP Window7 ,Vistar

specification:

Description:
1.Good visualization
Glassbased design allows the light to pass through the glass without any influence to the building structure around.Transparency of the glass screen can up to 85%.
2.Ultra-thin, and ultra-light.
The thick can up to 1cm, and the weight can up to 7kg/m2
High brightness, and high definition.
The brightness can up to 6500 cd/m2.
4.Easy and convenient maintenance.
It can be maintained from inside, safer and more convenient.
5.Saving lighting costs of the whole building.
Besides good advertising effect, LED glass display also helps lighting the glass wall, thus makes the glass wall more attractive and saving a lot lighting cost.
6.Wide use range.
Wherever the glass wall is, glass LED display can be installed. Such as bank, supermarket, theater, business street, hotel, public civic buildings, and landmark buildings, etc.

Applications:
Widely used in glass curtain wall places, such as banks, shopping malls, theaters, commercial streets, stores, hotels, municipal public buildings, landmarks and other advertising.


Packing and transportation

Professional packaging:wooden box or flight case.
The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.
Faultlessly solve your worries in the transportation.



About Hero

8-year's experience in LED screen, our factory has the ability of processing, researching and developing led display to ensure the prolificacy.A strict quality control process to make sure the led display screens is with high quality.

After-sale service
1) Warranty:
Free to solve the quality problems to ensure that equipment normal operation in the warranty period . At any time, we bear all the responsibility, when the problem is from the product itself.
2) Free maintenance:
Free warranty in the warranty period.
Only charge the cost of raw materials, provide spare parts and maintenance services for the lowest price after the warranty period.
3)quick response:
Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
4) Free support:
Through telephone or network to provide service support in real time, or with the help of a network for remote debugging support (software), to solve the problem.

For more led information about p10 led display moudle with high performance  ,welcome to our officer website:http://www.led-hero.com


Prod Model: P10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Lifespan: 100,000 Hours
Warranty: 2 Years
Bringhtness: 850~1000CD./Sq.M
Display Type: LED Video Display
Tube Chip Color: Full Color
Display Function: Video Display
Scanning Mode: 1/8 Scan
Certification: EMC
Pixel Configuration: 1R,1G,1B
Pixel Pitch: 10mm
Pixel Density: 10,000 dots / m²
Application: Shopping Guide
IP Rating: IP43
System Operating Platform: Winxp Win98,Win7
Shenzhen LED-HERO Electronic Telechnology Co., Ltd was found in early 2007. Hero committed to the next generation of LED optoelectronic products development, production, sales and service. It is leading the trend of LED industry and providing a full range of solutions to its customers. It has become a modern, large scale, professional LED Photoelectric comprehensive product integration supplier. The products sell well in over 50 countries and regions in Europe, America and Middle East, besides more than 20 provinces across China.

"Hero' S products and solutions include various of indoor and outdoor LED display screen and lighting products with its advanced technology, superior technology design, personalized design elements, large-scale production capacity and diversified cooperation strategy to provide full LED integrated solutions.

"Beat by wisdom, win in morals"is still our insistent faith, Quality is the life of a company. From material purchasing to product researching, development, production, testing, packaging and shipment, Hero abides ISO9001: 2000 international quality control process to make strict control and scientific management, and to achieve perfection. The products have passed the RoHS, CCC, CE and other international quality certification which ensure that each product are stable, reliable, environmental protective.

Excellent talent is the soul. Hero relies on the humanized management, promoting hero culture, exerting employees to have masters spirit. It has established a systematized, specialized production procedure. And it has built a strategic alliance with LED raw materials suppliers and vendors which has realized the resource sharing, division, cooperation, mutual complementarities and high-efficient operation for providing an effective guarantee to Hero' S scale production and diamond quality.

To select Hero, you will win the promise of a hero!
