Home LED Light Products SMD Indoor P6 LED Display

SMD Indoor P6 LED Display

SMD Indoor P6 LED Display
Price: US $ 800-900/Square Meter
Trade Terms: FOB,CIF,EXW
Min Order: 5/Square Meter
Pay Type: T/T
Specitication:P6 LED Panel Specification
NO:Product NameSpecification
1Pixel Pitch6mm
2Pixel Configuration1R1G1B/SMD3528
3Density27,777 pixel/m2
4Moduel Size(L×W)mm192mm×192mm
5Cabinet Size(L×W×H)mm768mm×768mm×130mm
6Module Resolution32×32
7Cabinet Resolution128×128
8Driving Method1/8 Scan
9Driving ICMBI5024
10Brightness1800cd/m2
11Contrast1000:01:00
12Brightness AdjustmentAC 85-264V
13Power ConsumptionMax Power:<900W
14Average power: <320W
15Cabinet Weight<15kg
16Color Temperature3200K-9300K
17Horizontal Viewing Angle120º
18Vertical Viewing Angle90º
19Signal Processing10 or 14bit
20Grey Processing1024×1024×1024
16834×16834×16834
21Control DistanceCable100m,Multimode500m,Single mode
2km
22Frame Frequency60 Hz
23Refresh Rate>600Hz
24Control ModeSynchronous/Asynchronous
25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve

26Users can choose the recommended curve, also can be adjusted according to actual situation

27MTBF≥50000 hours
28Life Span100,000 Hours
29Operating TemperatureWorking : 35 - 90°C
30Storage : 10 - 99°C
31Environment Temperature-30°C to 60°C; humidity Rh10% to 95%
32Remote ControlCan realize remote control,For the possibility of potential failure logging, and send alarm signal to the operator (need to customize)

33Self-checking TechniqueLED a single point of self-inspection, communications test, power test, temperature monitoring (need to customize)

34System Operating PlatformWindowsNT,Windows2000,WindowsXP,Windows7
35Power SupplyAC 85-264V
36Protectionwaterproof, dustproof, high temperatureproof,anti-corrosion, anti-burning,anti-static,shake proof,thuner-proof,the system with smoke alarm and temperature alarm function. (need to customize)


PACKAGING&SHIPPING
1)Within 15-27 days after receiving deposit.
2)Wooden case, plywood case and flight case choosen by customers.

OUR SERVICE

1)We guarantee all our display, modules, spare parts for ONE years after consignment from factory.
2)We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3)After warranty, we also can offer you the parts for replacement at our bottom price.
4)After sales, if you have any problem about our product, you can inform us by e-mail, we will reply you at once when we get it and offer you a good solution to solve the problem.

COMPANY INFORMATION

Shenzhen Teeho Optoelectronic Co.,Ltd. is a professional LED display R&D production, sales as one of the world's best solution providers. Companies registered capital of 10 million, employs more than 300 people. Trina Industrial Park covers an area of 10000 square meter, is equilipped with automatic-equipped automatic production lines, can produce up to 8000 square meters.

Teeho Optoelectronics was founded several years,accounting for 10% of the total R&D engineering team of professional staff, laid the foundation for new product development and Teeho to meet customer specific applications, we have developed a variety of high-definition screen, and in the high-end indoor and outdoor full color resolved program areas achieved impressive results. We have passed the ISO9001:2000,CCC,CE,FCC,RoHS and other qualifications.

CONTACT US

Add:Building B,Longda Industrial PARK .Liaokeng Village,Shiyan Town,Baoan District,Shenzhen,Guangdong,China(Mainland).
TEL:+86 15679472655
Fax:+86 75529438791
Website:www.teeholed.com



Prod Model: TeehoLED PH5
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LED Chip: Epistar, Sanan, Nationstar
Power Supply: Chuanglian, Chenglian, G-Energy, Meanwell
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 6mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 27,777 dots / m²
Scanning Mode: 1/8 Scan
Display Type: LED Video Display
Application: Shopping Guide
IP Rating: IP43
Certification: CCC
System Operating Platform: Winxp, Win7, Win2000, Win8
Shenzhen Teeho Optoelectronics Co. Ltd(short for Teeho Optoelectronics), found in 2009, is a high-tech private enterprise specialized in LED Screens manufacturing with a ¥ 11 million of registered capital and over 300 employees in Shenzhen. It has been dedicating itself to offering one-stop LED display solutions to its customers including R&D, prototyping, assembly, sales and technology support across the globe.

Teeho industrial park is located in Bao'an, Shenzhen, the most populous LED industrial area, with a cover of more than 10, 000 m2 and over 300 million of amount of sales per year, fully equipped with modern automatic assembly lines with the manufacturing capabilities of 8000 m2 per month

Teeho Optoelectronics spans a wide range of products covering: Indoor Full-Color LED Displays, Out Full-Color LED Dislays, LED Television Displays etc, applied to governmental institutions, corporate image projects, business ads, media activities, cultural and entertainmental places, stadiums, stations and airports etc.

Teeho Optoelectronics is focusing all efforts to technology-leading strategies of production by relying on the three-tier talent strategy, gathering high profile professional talents, which makes a foundation of new R&D of products and specially custom-made products. The R&D teams of Teeho electronics have been dedicating themselves to one-stop solutions, and have obtained tens of certifications of products and innovative patents. Moreover, they have outstandingly achieved in high-end indoor full color display solutions.

Teeho electronics has been promoting itself by advanced technology and scientific managements and has the following certifications: ISO9001: 2008 Quality System Certification, ISO1400: 2004 Environment System Certification, CCC, CE, FCC, RoHS etc. With high quality and perfect service, Teeho Optoelectronics has built lots of sales and service networks and its high-quality products has been exported into more than 80 countries and areas such as the United States, India, New Zealand. Japan, Thailand, Taiwan and Hongkong.

Teeho Optoelectronics Co., Ltd has been marching on under core values of Integrity, Pragmatic, Harmony, Creativity to guide our staff members and to devote itself to leading status in this industry, to ensure that our client will be fulfilled with the high-quality products and best service. With the horizontal developments in industrial chain and a variety of for-profit models, we vigorously promote the construction of brand culture, strive to become a world-class brand researched and developed independently, to become the most professional LED screens and one-stop solutions supplier, which makes a contribution to competing of national brands in globe markets.
