Home LED Light Products Shenzhen Manufacturer Indoor P6 SMD LED Panel Display

Shenzhen Manufacturer Indoor P6 SMD LED Panel Display

Shenzhen Manufacturer Indoor P6 SMD LED Panel Display
Price: US $ 520-580sqm
Trade Terms: FOB,CFR,CIF
Min Order: 1sqm
Pay Type: T/T,Western Union,Paypal
Factory price full color SMD indoor p6 led display led panel multi color led display, high quality, 2 years warranty .

Indoor Super Slim cabinet  feature

Super-slim and high transparency design, aluminum alloy cabinet, made the screen extremely light and also a good-looking;
Perfect distribution of light, allows you always get the best vision in spite of the viewing angle changing;
Special mask design, provide better protection for the LED lamp and better shading for the lights; Internally installed power supplier;
Good looking cabinet, quick for installation, and also easy to transport.


Feature  :
1 Super thin and light weight(weight :9KG, thickness :80mm),

 2 high refresh rate, high gray scale ,high contrast rate, perfect viewing effect.
  seamless connection and soft image.

       3 Energysaving, environmental protection, low power consumption with
average160 W/m², save more than 50% energy.

       4 easy and fast installation without tools, and both for fixed installation and
rental using,  support hot-plug connection, and safety operation.

       5 aluminum die-casting cabinet, flatness and uniformity screen with cabinet

       6 difference controlling within 0.1mm and screen gap within 0.5mm.
  both for fixed installation and rental using, various installation condition.


Full Color SMD Indoor P6 LED Display with factory price
Unit ModuleItem parameter
Model P6 FULL Color Led Module
Module size 192mm*96mm
Pixel Pitch6mm
Pixel Density27777dots/m2
Pixel Configuration 1R1G1B3 in 1
Module Resolution 32dots(W)*16dots(H)
Max power 20w
Module Thickness2.7cm
Module Weight 0.4kg
Driving MethodConstant Current Driving
Scan Method1/8scan
Interface WayHUB75
Brightness≥7000cd/m2
Unit ModuleCabinet Size 768mmx768mm
Cabinet Composing32pcs
Power supply Mode 5V/40A 5V/60A
Cabinet Resolution128*128dots
Optimal Viewing Distance5M-50M
Optimal Viewing angle160°(W)120°(H)
Enviroment TemperatureStorage :-35ºC-+85ºC
work :-20ºC-+50ºC
PowerRelative Humidity10%-95%
Operating Voltage AC220V±10%
Average power 350W/H
Max power Consumption ≤600W/m2
Current ≤20mA (Single LED )
Control systemComputerPentium4 or above P4 or above
Operate systemWIN98/2000/NT/XP
Control ModeSynchronization with PC
Main technical parameter Driving DeviceIC Constant current driving
Refresh Rate≥600HZ
Gray/ColorRGB each 256 grade, can display 16.7M clolor
MTBF≥9000hours
Power SwitchAutomatic Switch
Display Mode 800*600/1024*768/1024*900
Full Color SMD Indoor P6 LED Display with factory price


Using Range
Widely used in large venue,stadiums,bank,government,
terminal,dock,station,stock market,medical systems,
electricity,exhibition etc.


Prod Model: ALS-P6
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No: P6 Indoor Full Color LED Display
Module Size: 192*96mm
Mbtf: 9000hours
Cabinet: 576mmx576mm
Module Maximum Power Consumption: 15W
Port Type: Hub75-a
Module Thickness: 14.85mm
Driving Method: Constant Current Driving
Brightness: 3500CD/M2
Module Weight: 0.154kg
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 6mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 27,777 dots / m²
Scanning Mode: 1/4 Scan
Display Type: LED Video Display
Application: Shopping Guide
Certification: FCC
System Operating Platform: Win98/2000/Nt/XP
IP Rating: IP31
Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.

Features:

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
