| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 5/Square Meter |
| Pay Type: | T/T,Money Gram,Western Union |
| Model No | Galaxias 6 | Galaxias 7 | Galaxias 9 | Galaxias 12 | Galaxias 16 | ||
| Pixel Pitch | 6 mm | 7.8mm | 9.375mm | 12.5mm | 16mm | ||
| Density | 27778 Dot / m² | 16384 Dot / m² | 11378 Dot / m² | 6400Dot / m² | 3906 Dot / m² | ||
| Pixel Configuration | RGB 3-IN-1 SMD 2121 | RGB 3-IN-1 SMD 3528 | RGB 3-IN-1 SMD 5050 | ||||
| Brightness(White) | 2600 nit | 2730 nit | 2100 nit | 1650 nit | 1300 nit | ||
| Optima visual distance | 4.5m | 5m | 7m | 9m | 12m | ||
| Max.Power Consumption | 180 W/m² | 190 W/m² | 175W/m² | 185 W/m² | 230W/m² | ||
| Average.Power Consumption | 63 W/m² | 67 W/m² | 62W/m² | 65 W/m² | 80W/m² | ||
| Recommendation size (W=Width H=Height T=Thickness) | W: 800mm H: 2400mm T: 25mm | W:1000mm H:2400mm T: 25mm | W:600mm H:2400mm T: 25mm | W: 800mm H:3200mm T: 25mm | W: 1024mm H:2560mm T: 25mm | ||
| Weight | 11.5Kg/Sq.m | 11.0Kg/Sq.m | 10.4Kg/Sq.m | 9.8Kg/Sq.m | 9.2Kg/Sq.m | ||
| Work voltage | DC 24V | ||||||
| Brightness level | 16 levels | ||||||
| Bit depth per color | 16 bit | ||||||
| Bit depth per pixel | 48 bit | ||||||
| Visual Angle | Horizontal: 120; Vertical: 120 | ||||||
| Data Refresh Rate | ≥10000Hz | ||||||
| Display mode | 1280×1024 | ||||||
| Drive mode | Constant current | ||||||
| Signal type | AV,S-Video,VGA,CVBS,HDMI,DVI | ||||||
| Operating System | Windows2000/XP/Vista/Windows7 | ||||||
| Control Distance | HSYV; <100m | ||||||
| Face material | DFR velvet drapery | ||||||
| Ingress Protection | IP 43 | ||||||
| Ambient Temperature | -20 ~ +50 °C | ||||||
| Relative Humidity | 10% ~ 90% | ||||||
| Installation | Hang | ||||||
| Power system | Power-600, Power-1200 Power system | ||||||
| Safety certificate | CE FCC ROHS | ||||||
| Prod Model: | Galaxias-12 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Pixel Configuration: | 1R,1G,1B |
| Scanning Mode: | 1/8 Scan |
| Display Type: | LED Video Display |
| Application: | Stage Performance |
| IP Rating: | IP43 |
| Certification: | RoHS |
| Pixel Pitch: | 12.5mm |
| Pixel Density: | 6400 Dots/Sq.M |
| System Operating Platform: | Win7 |
