Rental Indoor Advertising Full Color LED Display (LED screen, LED sign)
Key features:
1. 6.67mm, 8mm, 10mm SMD outdoor, 10mm, 13.3mm, 16mm, and 20mm DIP outdoor, wide range of products
2. outdoor IP65 proteciton, rear service & front service available
3. Weather proof, IP65
This product has been introduced to market for over 10 years, with well known quality and reputation, especially, the P10 DIP outdoor, is one of the most competitive worry-free product.
Before delivery, all our products are going to be aging test at least 72 hours, to ensure everything is ok.
Goods check & inspection before delivery, factory technic training program, etc., provided upon request.
To experience our VIP service and everything, please always feel free to get in touch with us .
Our factory
To experience our vip service, feel free to get in touch with us at
[email protected] Main Parameter |
Category | Parameter |
Pixel Pitch | 10mm |
Optimum Viewing Distance | 10-25m |
Density of Pixel | 10000pixels/ |
Brightness | ≥5000nite | ≥6500nite |
Module Resolution | 32*32 |
LED Encapsulation | DIP346 1R1G1B | SMD5050 1R1G1B |
Driving Method | Real 4 Scan | Real 2 Scan |
Optimum Viewing Angle | H: 110°V:50° | H: 120°V:100° |
Module Size | 320*320*28.4(mm) | 160*160*22.5(mm) |
Module Power | 50w | 70w |
Module Weight | 1200g | 1100g |
Cabinet Size | 960*960*178.4(mm) | 960*960*173(mm) |
Cabinet Resolution | 96*96 |
Cabinet Power | 1125w | 1100w |
Cabinet Weight | 55kg | 49kg |
IP Rating | Front/Rear:IP65/IP43 |
Refresh Rate | 1000-4000Hz( Different according to the different Driving IC ) |
Luminance Consumption | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature25ºC. |
MTBF | >5000hours |
Defective Dot Rate | <0.0001 |
Life Span | >100000hours |
Working Voltage | 110-240 AC±10% 50-60Hz |
Working Temperature/Humidity | -30ºC- +50ºC/10-90%RH |
Storage Temperature/Humidity | -40ºC- +60ºC/10- 90%RH |
Input Signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc |
Connector | CAT5 Cable(Length≤1430m),Optical link(Length≤20km,Optional) |
Note: The above parameter is just for reference. Changes can be made according to customers' requirements. |
Located in Baoan District, Shenzhen Myled Optech is an professional LED display manufacturer which is dedicated to LED display R&D; Production, sales, marketing and one stop solution for customers mainland and international. Myled provides consulting, installation, training and sales services for customers. We always regard customers as the company life line.
Shenzhen Myled Optech focus on indoor and outdoor full color LED display, LED curtain display, mesh, indoor and outdoor single and bicolor LED display manufacturing. We have established business relationship with customers in South America, Euro, and Asia etc. And win a good reputation among customers all over the world. And we provide full solution for Government, Telecom, Hotel, airport, bus station, stadium, and cinema and financial center, etc. Over the past years, we have finished some important LED display project for South American and China Mainland.
Quality is the most important theme for Myled and welcome to contact, and visit our company.
We hold the truth that better quality, better price and better sales services are our company culture.
