Professional Manufacturer of Indoor P7.62 Full Color LED Display

About Us:
Shengzhen Mountain A-Li Group Electronic Technology Co., LED.
is a professional company manufacturing LED display system products for more than 10 years, established in 2000, covering a workshop area for 2000m2, with about 300 employees.

Products list:

Item No.:	Description	Dimension	Brightness
	INDOOR
1	SMD indoor p3mm	192mm*96mm	2000cd/m2
2	SMD indoor p4mm	256mm*128mm	2000cd/m2
3	SMD indoor p5mm	320mm*160mm	2500cd/m2
4	SMD indoor p6mm	192mm*192mm	3000cd/m2
5	SMD indoor p7.62mm	244mm*244mm	2000cd/m2
6	SMD indoor p10mm	320mm*160mm	3000cd/m2
	OUTDOOR
7	DIP 3in1 outdoor P6	192*96mm	7500cd/m2
8	DIP 3in1 outdoor P7	224*112mm	7500cd/m2
9	DIP 3in1 outdoor P8	256*128mm	8000cd/m2
10	SMD 3in1  outdoor P6	192mm*192mm	6000cd/m2
11	SMD 3in1  outdoor P8	256mm*128mm	6500cd/m2
12	DIP 3in1 outdoor P10 round screen	320*40mm	8500cd/md
13	outdoor p10mm	160mm*160mm	8500cd/m2
14	outdoor p12mm	192mm*192mm	7500cd/m2
15	outdoor p13.33mm	320mm*160mm	5500cd/m2
16	outdoor p16mm	256mm*256mm	7500cd/m2
17	outdoor p20mm	320mm*320mm	7000cd/m2

Our Advantages:
1.High quality:
   Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.

2.Good effect:
   To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.

3.Easy maintenance:
    Can fix the single point to save the maintenance cost.

4.Good uniformity:
    Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well

5.Price
    No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!

6.Application
   It's wide Application, such as stage rental events, exhibition, wedding, advertising, meeting room and so on.


Features Introduction:
1)High intensity and can be adjusted, so can meet the request of the customers according the application environment.

2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light

3) To pictures and character, have clear, exquisite and real display effect

4) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.


 Parameter

The specifications of modules
Items	Parameter
Product Model	P6 Indoor Full Color Led Module
Module size	244mm*244mm
Pixel pitch	4mm
Pixel density	17222dots/m2
Pixel configuration	1R1G1B
Module resolution	32dots(W)*16(H)dots
Module maximum power consumption	15W
Module Thickness	15MM
Module Weight	0.45kg
Driving method	Constant Current Driving
Scanning method	1/48 scan
Interface	HUB75-A
Brightness	≥ 1700cd/m2
The specifications of cabinets
Cabinet size	976mm*976mm
Module quantity	16pcs
Power supply	5V/40A 5V/60A
Cabinet resolution	128*128dots
Optimal viewing distance	8M~100M
Optimal viewing angle	160°(W) 120°(H)
RHWorking temperature	(Work :-20°C~+60°C)
System operating humility	10%-95%
The specifications of power supplier
Operating Voltage	AC220V±10%
Average power consumption	350W/H
Maximum power consumption	≤400W/M2
Electric current	≤20mA(single LED)
The specifications of control card
Control Panels	Pentium4 or above
Operating system	WIN98/2000/NT/XP
Control model	Synchronization with PC
The specifications of the main technical parameters
Driving device	Constant Current Driving
Refresh rate	≥600HZ
Grey scale	RGB Each 256, can display 16.7M colors)
MTBF	≥9000hours
Power switch	Automatic Switch
Display Mode	800*600/1024*768/1280*900
