Main Functions
1.Blue-tooth music player
Paired with a phone,music player software can support many kinds of online play, can also see the lyrics and switch songs anytime.
2.Blue-tooth Hands-free
The range of bluetooth connection up to 10 meters with non-barrier,built-in high quality microphone, speakerphone distance up to 3 meters and without noise.
3.Mobile power function
2100 MA can be filled with 1.5 to 2.5 times phone normally.
4. LED lighting function
Used as bicycle headlights, LED night lighting up to 50 meters.
5. The battery life
With high-efficient lithium battery inside, 3 hours LED lighting, 25 hours of continuous music broadcasting, 44 hours speakerphone, the longest standby time can be long for 100 days.
Features
1. Use of environmentally friendly energy-efficient LED technology,high quality surface treatment.
2. Bulit-inside Hi-Fi high-quality efficiency speaker monomer,even when used outdoor activities,it also can be released pleasant music.
3. Built-inside high-capacity rechargeable battery, super long-time playing and mobile power functions.
Parameters
Electrical parameters
USB models:Standard USB2.0
Input Voltage:DC5V
Charging current:0.9A
Charging ways: first constant voltage
then constant current
Output Voltage:DC 5V
Output Current:1A
Rechargeable batteries cutoff voltage:4.2V
Discharge cut-off voltage battries:3V
Bluetooth parameters
Bluetooth version: V4.0 + EDR
Bluetooth solution: CSR
Bluetooth protocol: A2DP, AVRCP, HFP, HSP
Sensitivity: 106DB
Transmission distance:Accessible ≤ 15 m
Bluetooth equipped against
the password: 0000
Bluetooth equipped against the name: MultiSpeaker
Battery parameters
Battery capacity:2100mAH
Charging time:2.5-3H
Continuous music playback time:25H
Continuous talk time:45H
LED lighting time:3H
Standby time:100 days
Protection circuit
Over-discharge protection:
When the battery voltage is too low, the output is automatically turned off
Current protection:
When the load current exceeds 1A, 1A output current limiting automatically
Short circuit protection:
Supports output short circuit protection devices
Battery Protection:
Built-in battery protection circuit
