Outdoor DIP Rental Full Color LED Display
Product Features
1, adopt the high quality LED lamps with black appearance, high brightness, less lumens depreciation, broaden viewing angles in horizontal and vertical.
2, Use private mold and special texture design on the surface, choose the 100 % PC as the kit materials with the characteristics of: Stable shapes, non-crackle, good tenacity, and high evenness for even split joint, , which is properly long-time used for outdoor.
3, IP65, Fire protection grade 94CV0, UV proof, resistance of high and low temperature, and acid base salty mist.
4, the whole raven is uniformity; Contrast ratio of the screen is very high, white balance is conformity, displaying color is uniformity, and the picture definition is high.
5, Supports signal flow randomly, satisfies different array and putting in order to create different image effects.
6, Equips professional video processor, which supports signal formats like AV, DP, VGA, DVI, YPbPr, HDMI, SDI etc.
|
|
ITEMS |
P10 |
|
Module |
Pixel Pitch |
10mm |
|
Pixel Density |
10000dots/m 2 |
|
Led Lamp Type |
DIP |
|
Led Configuration |
1R1G1B |
|
Module Size |
160× 160mm |
|
Module Resolution |
16× 16 |
|
Scan Mode |
1/4 Duty |
|
Drive Mode |
Constant Current |
|
Cabinet |
Cabinet Size |
800× 640mm |
|
Cabinet Resolution |
80× 64 |
|
Module Quantity |
20 |
|
Cabinet Weight |
55kg/m 2 |
|
Display |
Brightness |
≥ 6500cd/m 2 |
|
Contrast Ratio |
≥ 4096: 1 |
|
Viewing Angles(H/V) |
120° /60° |
|
Min. Viewing Distance |
10m |
|
Gray Scale |
≥ 12bits/4096level |
|
Colors |
68.7billion |
|
Power Supply |
Average Power Consumption |
250w/m 2 |
|
Working Voltage |
AC 90 to 260V, 50 to 60Hz |
|
Control System |
Frame Changing Rate |
60 to 85Hz |
|
Refresh Rate |
600 to 4000Hz |
|
Brightness Adjustment |
0 to 100% |
|
Ganma Correction |
(-0.5 to 5.0) |
|
Color Temperature |
3000 to 9300K |
|
Brightness Correction |
By Pixel, Module, Cabinet Correction |
|
Data input Source |
AV, S-Videom, VGI, DVI, HDMI, SDI, DP |
|
Control Method |
Synchronization with computer |
|
Data Transmission Distance |
100m by UTP CAT5; 500m by Multi Optic Fiber; 10km by Single Optic Fiber |
|
Operation Environment |
Windows(2000, XP, Vista, 7) |
|
Reliabilty |
Storage Temperature |
(-40 to 85)centi degree |
|
Working Temperature |
(-20 to 50)centi degree |
|
Working Humility |
10% to 90% |
|
MTBF |
5000Hrs |
|
IP Rating |
IP65/IP43(Front& Rear) |
|
Blind Spot Rate |
≤ 0.01% |
|
Lifespan |
100, 000Hrs |
