Main Features:
User can arrange any display modes at will, like display text, graphics,images,animations, video information, with unlimited display amount
· With super-high brightness LED, high contrast
· High frame frequency, wider view angel
· With module development and distributed scan
· technology, high reliability
· Universal AC input / full range
· exhibition modular design makes installation and maintenance more easier
· PC synchronous or asynchronous control(optional)
· Use common video play software, easy to use
· 2 years warranty
Parameter
The specifications of modules |
|
Items | Parameter |
Product Model | P8 Outdoor Full Color LED Module |
Module size | 256mm*128mm |
Pixel pitch | 8mm |
Pixel density | 15625dots/m2 |
Pixel configuration | 1R1G1B |
Module resolution | 32dots(W)*16dots |
Module maximum power consumption | 25W |
Module Thickness | 2.8CM |
Module Weight | 0.55kg |
Driving method | Constant Current Driving |
Scanning method | 1/4scan |
Interface | HUB75 |
Brightness | ≥7500cd/m2 |
The specifications of cabinets |
|
Cabinet size | 768mm*768mm |
Module quantity | 18pcs |
Power supply | 5V/40A 5V/60A |
Cabinet resolution | 96*96dots |
Optimal viewing distance | 8M~50M |
Optimal viewing angle | 160°(W) 120°(H) |
RHWorking temperature | (Work :-20°C~+60°C) |
System operating humility | 10%-95% |
The specifications of power supplier |
|
Operating Voltage | AC220V±10% |
Average power consumption | 330W/H |
Maximum power consumption | ≤600W/m2 |
Electric current | ≤20mA(single LED) |
The specifications of control card |
Control Panels | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control model | Synchronization with PC |
The specifications of the main technical parameters |
|
Driving device | Constant Current Driving |
Refresh rate | ≥600HZ |
Grey scale | RGB Each 256, can display 16.7M colors) |
MTBF | ≥9000hours |
Power switch | Automatic Switch |
Display Mode | 800*600/1024*768/1280*900 |
Advantage:
1. High brightness and be adjustable. Built-in functional card support brightness automatically adjustment.
2. A turn-key solution including professional sports software and hardware.
3. Rich advertising LED display screen engineering experience both in domestic and oversea market.
4. Elnor product stability through strict quality control system.
5. Price Advantage: Best competitive price for Elnor p8 led display outdoor.
6. Performance Advantage: Best equality, high consistency, High refresh rate, high consistency, Best brightness, big viewing angle...
7. Quality advantage: From material to finished product, from design to produce, we control all steps, include the guarantee of the quality and reliability.
8. Service advantage: with professional service team for 24 hours service, Better service at same situation, better cooperation at same service.
Service:
1. Your inquiry related to our products or price will be replied in 24hrs as soon as possible.
2. Protection of your sales information,ideas of design and all your private information
3. Top quality+ reliable price+responsible after service=successful
Technology Training:
1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.
Documents and Certification:
1. We provide the operation manual, software, test report and so on.
2. We can also provide all kinds of certification such as CE, UL and so on.
CAD Drawing and Fixing:
1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.
