Home LED Light Products P7.62 Indoor Full Color LED Display

P7.62 Indoor Full Color LED Display

P7.62 Indoor Full Color LED Display
Price: US $ 400-500/Square Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1/Square Meter
Pay Type: L/C,T/T,Paypal,Western Union
P7.62 LED Display Strip
1. UL, CE&RoHS certificate
2. Excellent visual effect
3. Low power consumption
4. Life Span: 100, 000hrs
5. Warranty 5year
Features and Advantages

1. In order to ensure that images and tests are clear, vivid and consistent, all the chips for the entire RGB LED screens for outdoor screens within 100 square meters are at the same grade such as the same brightness and the same wavelength.

2. In order ensure screen background can become matt, completely absorb LED reflective light and eliminate shadow and ghosting, we adopt imported glue to varnish module surface, the glue thickness for each module is not more than 0.1mm, so the color is consistent and uniform.

3. To ensure product reliability and long life, we select the best chips for all outdoor display, red chips are from Hitachi brand, blue and green ones come from US CREE.

4. Easy to maintain and achieve single-pixel and single-lamp maintenance.


5. High quality at competitive prices. 6. Wide applied in stadiums, advertisemjent, banks, securities exchange, stations, entertainment, shopping malls, postal offices, schools, monitoring, restaurants, enterprises etc

The technology parameter  of P7.62 indoor

ItemP7.62
1Pixel pitch7.62mm
2Size of unit board244mm X 122mm
3Resolution of unit board32X 16
4Density of pixel17222dots/m2
5Pixel configuration1R1G1B
6Red wavelength625±2nm
7Green wavelength525±2nm
8Blue wavelength470±2nm
9Colors16777216
10Best viewing distance≥8m
11Horizontal viewing angle140°
12Maximum power consumption600~1000W/m 2
13Brightness2000-5000cd /m 2
14Gray scale16bits per color
15Color temperature6500k
16Control methodSynchronization & Asynchronization
17Driving method1/16 or 1/8 scanning
18Frame frequency60Hz
19Refresh frequency350Hz
20Working voltageAC220V/110V±10%
21IP gradeIP20~IP65
22Working temperature-20°C~80°C
23MTBF>10000 hours
24Life span>100,000 hours
25Computer operation system Win XP/Vista/ Win 2000/WIN7ect.
26Video signalRF, S-Video, RGB, RGBHV, YUV, YC.ect
Prod Model: P7.62
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty: 3 Years
Color: Full Color
LED Chip: Epistar Fromtaiwan
Best Viewing Distance: 7-150m
Frame Frequency: 60Hz
Refresh Frequency: 350Hz
Life Span: 100,000hours
Mtbf: 10000 Hours
Certificate Approved: CE,RoHS,SGS
IP Grade: IP 60
Tube Chip Color: Full Color
Display Function: Video Display
Pixel Pitch: 7.62mm
Pixel Configuration: 1R,1G,1B
Pixel Density: 17,222 dots / m²
Scanning Mode: 1/8 Scan
System Operating Platform: WIN XP
Display Type: LED Video Display
Application: Shopping Guide
IP Rating: IP60
Certification: SGS
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.

As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.

Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.

Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.

With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
