P6mm Flexible & Soft Full Color Indoor LED Curtain Display
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB |
| Min Order: |
5/Square Meter |
| Pay Type: |
T/T |
Model No.: Rubik 6
Pixel Pitch: 6.64mm
Density: 22682 pixel/m2
Pixel configuration: RGB 3-in-1 SMD
Brightness (white): 2200nit
Optima visual distance: 5m
Max. power consumption: 280W
Average power consumption: 93W
Module Size: W=425mm L=212.48mm T=25mm, 64 (W) X 32 (L) pixels
Recommended size (customized): W=425mm L=1700mm T=25mm, 64 (W) X 256 (L) pixels
Weight:10.5kg/sq.m
Work voltage: DC 24V
Brightness level: 16 levels
Bit depth per color: 16 bit
Bit depth per pixel: 48 bit
Visual angle: Horizontal:120°, Vertical:120°
Refresh rate: ≥7000Hz
Display mode:1280 X 1024
Drive mode: Constant current
Signal type: AV, S-Video, VGA, CVBS, HDMI, DVI
Operate system: Windows 2000/ XP/ Vista/ Window7
Control distance: HSYV<100m
Body structure: Plastic, metal
Ingress protection: IP43
Ambient temperature: -20~+50
Relative humidity: 10%~90%
Power system: Power-600, power-1200
Installation: Hang
| Prod Model: |
Rubik 6 (P6.64mm) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Weight: |
Less Than 10kg/Sq.M |
| Thickness: |
Less Than 25mm |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Scanning Mode: |
Static Scan |
| Application: |
Nightclub, Concert |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Pitch: |
6mm |
| IP Rating: |
IP43 |
| Certification: |
RoHS |
| Pixel Density: |
27,777 dots / m² |
| System Operating Platform: |
WIN XP |
Huasun Technology Co., Ltd. is a high-tech enterprise that is engaged in the researching, developing, producing, marketing, and engineer service of LED display and LED lighting. It has been grown in Beijing, capital of China, for over ten years. The main products and services include LED display system, LED digital stage system, LED lighting system. With a business principle of technological innovation and professional service, the company commits to provide high-quality LED products and solutions for all clients.
The company has a R&D team made up of senior engineers. Taking advantage of the technological and cultural resource in the Capital of China, working together with experts in mechanism, optics, and electronics from the main universities, the team is devoted to the research and application of multimedia technology and has gained the leading position in product design, software development, mechanical design and optical application. The company has own many national invention patents in LED display technology. Flexible LED display, one of our patents, is a landmark product in the development of LED display. It is widely used by the clients from all over the world for the advantages of compact size, light weight, and easy installation. We always keep in mind that the mission and responsibility of the enterprise is to change the world by pioneer spirit and innovative product in a technology high speed age. We are always proud of it.
Welcome to future of Huasun: A brighten future.
