P6 Indoor SMD LED Display
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Box |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
P6 SMD LED Display, Supper Clarity & Low Gray Level, Energy Saving for High Efficiency, Large Viewing Angle, High Uniformity, High Reliability, Excellent Color Mixing.
| Parameters | NP6-SMD |
| Pixel | Pixel Set | 3528 LED 1R1G1B | 3528 LED 1R1G1B |
| Pixel Pitch(mm) | 6 | 6 |
| Pixel Density(Pixel/m2) | 27777 | 27777 |
| Module | Module Resolution(W/Pixel × H/Pixel) | 64 × 32 | 32 × 32 |
| Module Size(W/mm × H/mm) | 192 × 192 | 192 × 192 |
| Cabinet | Receiving Card Covering (W/Pixel × H/Pixel) | 128 × 128 | 128 × 128 |
| Cabinet Flatness(mm) | ≤ 1 | ≤ 1 |
| Maintenance | Frontside Maintenance | Frontside Maintenance |
| Optical | Do-by-Dot Calibration | Available | Available |
| Brightness Balanced(cd/m2) | ≥ 800 | ≥ 2000 |
| Brightness Adjustment | 256 Grades Manually / Automatically | 256 Grades Manually / Automatically |
| Color Temperature(K) | 3000 - 10000 Adjustable | 3000 - 10000 Adjustable |
| Horizontal View Angle( °) | 120 | 120 |
| Vertical View Angle( °) | 120 | 120 |
| Brightness Uniformty | ≥ 95% | ≥ 95% |
| Electrical | Max Power Consumption(W/m2) | 180 | 600 |
| Average Power Consumption(W/m2) | 60 | 200 |
| Input Voltage | AC110~240V(50-60Hz) | AC110~240V(50-60Hz) |
| System Process | Driving Mode | Constant(1/16 Scanned) | Constant(1/8 Scanned) |
| Frame Rate(Hz) | 60 | 60 |
| Refresh Frequency(Hz) | ≥ 2400 | ≥ 2400 |
| Grey Scale(Bit) | 14 | 14 |
| Color Capacity(Trillion) | 4.4 | 4.4 |
| Enviromental | Typical Lifetime(h) | 80000 | 80000 |
| Operating Temperature(ºC) | -20 ~ +50 | -20 ~ +50 |
| Storage Temperature(ºC) | -35 ~ +85 | -35 ~ +85 |
| Operating Humidity(RH) | 10% ~ 90% , No Condensing | 10% ~ 90% , No Condensing |
| Storage Humidity(RH) | 10% ~ 90% , No Condensing | 10% ~ 90% , No Condensing |
| Functional | Available for Dot-by-Dot Calibration |
| Available for Signal Dual Backup |
| Available for being controlled by Cedar RTM Software |
| Available for different signal format, such as AV,S-Video,VGA,DVI,HDMI,SDI,DP etc. |
| Most of parameters can be customized according to requirements or special enviroments |
| Prod Model: |
P6 led display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| DOT-by-DOT Calibration: |
Signal Dual Backup |
| Matching Rtm Software: |
High Density |
| Display Function: |
Video Display |
| Pixel Pitch: |
6mm |
| Pixel Configuration: |
1R,1G,1B |
| Display Type: |
LED Video Display |
| Application: |
Monitoring, Education, Conference, Transportation |
| IP Rating: |
IP54 |
| Certification: |
FCC |
| Pixel Density: |
27777 Pixel/M2 |
| Scanning Mode: |
1/32 Scan |
| System Operating Platform: |
All System |
