P6 Full Color LED Module Outdoor Advertising LED Screen LED Display

P6 Full Color LED Module Outdoor Advertising LED Screen LED Display
Price: US $ 980-1050/Square Meter
Trade Terms: FOB,EXW
Min Order: 1/Square Meter
Pay Type: T/T,Western Union

Our products:
    We specialize in producing and developing all kinds of led displays. As a reliable LED Display manufacturer and exporter in China, we supply Indoor led displays, Outdoor led displays, semi-outdoor led displays.Please kindly tell me which kind of the item you prefer to and provide me more information. It will help us to give you a good price.





Our features and advantages:
1.High quality:
    Use high quality LED with high luminous efficiency and low brightness decay to make the display stable.

2.Good effect:
    To show vivid and clear pictures with high resolution, but low cost; Has good display effect in both pictures and letters because of using real pixel technology.The products support multiple display modes.

3.Easy maintenance:
    Can fix the single point to save the maintenance cost.

4.Good uniformity:
    Brightness difference within 10% between any two LEDs, to ensure the brightness and color uniformity of the display; Good uniformity in color solve the problem of mosaic well

5.Price
    No. 1 cost effective. The price is very good, please contact us for an offer. You can compare and know!

6.Application
    It's wide Application, such as stage rental events, exhibition, wedding, advertising, meeting room and so on.




FAQ:
1. Are you manufacturer? If yes, in which city?
    Yes, we are the professional manufacture of LED display, and we work on it more than 10 years. Our company in Shenzhen, Dongguang, China.

2. Can I visit your factory ?
    We warmly welcome customers visit us. Before you come here, please kindly tell me your schedule, we can arrange for you. The nearest airport is Bao'an Shenzhen international airport.

3. How about your quality warranty?
    2 years quality warranty and lifetime technology support and maintenance from the second year. If you improperly operate or something wrong with our products, we are responsible for the maintaining and repairs instruction or guide free of charge.





Remarks
1.Payment term:
    30% T/T in advance and balance before delivery.

2.Delivery time:
    Within 15 working days after 30% advance payment.

3.Free training:
    You can send your engineers who have knowledge of electronics and information to our factory and we provide free technical training, which contains training operation and maintenance of the LED display at our factory. We also offer the instruction manual, software, test report, drawing steel structure and so on.

4.Installation:
    We offer you the engineer to install the LED display, you have to offer him the two-way air tickets and accommodation as well as visa. The engineer's salary is $80/day;or we offer you the training on the LED display installation and repairing for free after you live in our company, or we can guide you to install the screen by remote control.

5.Service after sales:
    If you have any questions about our product, you can inform us by mail or call, and we will reply you in 24 hours when we get you E-mail or call, and offer you a good solution for your problem.




We are the best


Certificates


Parameter

The Technical Parameters of  p6 led screen Dip 3 in 1
The specifications of modules
ItemsParameter
Product Model P6 Full Color Led Module
Module size192mm*96mm
 Pixel pitch 6mm
 Pixel density  27777dots/m2
Pixel configurationRGB 3 in 1
 Module resolution32dots(W)*16dots(H)
Module maximum power consumption20W
 Module Thickness2.7CM
Module Weight0.4kg
Driving methodConstant Current Driving
Scanning method1/8 scan
InterfaceHUB75B
Brightness  ≥7000cd/m2
The specifications of cabinets
Cabinet size768mm x 768mm
 Module quantity32pcs
 Power supply5V/40A  5V/60A
Cabinet resolution  128*128dots
 Optimal viewing distance5M ~ 50M
Optimal viewing angle160°(W) 120°(H)
 RHWorking temperature(Work :-40 degree~ +60 degree )
  System operating humility10%-95%
The specifications of power supplier
Operating VoltageAC220V±10%
 Average power consumption350W/H
 Maximum power consumption≤600W/ m2
 Electric current ≤20mA(single LED)
The specifications of control card
Control Panels Pentium4 or above
Operating system WIN98/2000/NT/XP
Control modelSynchronization with PC
The specifications of the main technical parameters
 Driving deviceConstant Current Driving
 Refresh rate≥2200HZ
 Grey scaleRGB Each 256, can display 16.7M colors)
MTBF≥9000hours
Power switchAutomatic Switch
Display Mode800*600/1024*768/1280*900
Prod Model: P6 Outdoor Full Color LED Display
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size: 192*96mm
Mbtf: 9000hours
Refresh: 2200Hz
Cabinet: 768mmx768mm
Outdoor LED Screen: 32dots(W)*16dots(H)
Module Maximum Power Consump: 20W
Module Thickness: 2.7cm
Module Weight: 0.4kg
Driving Method: Constant Current Driving
Brightness: Hub75b
Tube Chip Color: Full Color
IP Rating: IP65
Pixel Configuration: 1R, 1G, 1B
Display Function: Video Display
Average Power Consumption: 350W / m²
Scanning Mode: 1/8 Scan
Display Type: LED Video Display
Application: Advertising
Certification: ISO9001/EMC/FCC/CQC/Coc/IP65
Pixel Pitch: 6mm
Pixel Density: 27777dots/M2
Shenzhen Mountain A-Li Group Electronic Technology Co., Ltd Major In LED Modules and LED Display. Indoor LED Display have P3 P4 P5 P6 P7.62 P10 (Have difference cabinets types ). Outdoor have P6 P7 P8 P10 P16 (Have difference cabinets types ), LED Modules have single color, double color and full color, LED Display Have Indoor LED display, Outdoor LED display, Outdoor LED screen. Indoor LED screen, LED video display, LED Video screen, LED Advertising screen, LED Advertising Screen.

Features:

1) With good lightening accordance and no mosaic

2) LED advertising board can play different formats of image files, flash, WAV/MIDI, video signal from TV, video signal from video and other equipment

3) Different video frequency can be changed freely at the same time, and the image can be enlarged and reduced

4) High brightness, and can be adjustable, meets the need of changing requirement of customer in environment

5) Uses real pixels rather than virtual pixels, better viewing effect

Applications:

LED advertising board wide applied in stadiums, advertising, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
