P6 Full Color LED Display
HOT-Promotion! ! ! P13.33 Full-Color Outdoor led display wall
Applications: Outdoor all-weather environment and rental use. High brightness, high protection rating and high stability, suitable for close viewing and small size application.
Characteristics:
General Module which will make the display very flat and minimum gap between modules endow your LED display with an high-end products.
1. Special design which can make our LED panel both front and rear side maintainance accessible. This will greatly cut down the maintain cost.
2. Ultra high brightness (8000 Nit) with low power consumption (300W/M2).
3. High refresh rate (greater than 3380 Hz) with software adjustable, suitable for filming.
4. High grayscale (14 bits) with perfect visual performance.
5. High Contras ratio (2000: 1) with black mask and black coating technique.
6. Wide viewing angle (greater than 140 ° In horizontal).
7. IP65 protection rating.
8. Fast and easy to assemble and dismantle.
9. High reliability and long lifespan (MTBF ≥ 5000 hours).
Optional for upgrade:
1. Ultra-High refresh rate (greater than 3000 Hz) with software adjustable, suitable for filming.
2. High grayscale (16 bits) with realistic visual performance.
3. On-site pixel by pixel brightness and color correction bring greater uniformity.
Unit Module | Item | Parameter |
| Model Number | HX-P6- 16S |
| Module size | 192mm x96mm/192mm*192mm |
| Pixel pitch | 6mm |
| Pixels Density | 27777dots/m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD3528 |
| Pixel resolution | 32dots(W)*32 dots(H)
64dots(W)*32 dots(H) |
| Max Power | 15W / 20W |
| Module thickness | 14.85mm (without magnetic column) |
| 27.15mm (with magnetic column) |
| Weight | 0.304kg/ 0.602kg |
| Drive type | Constant drive |
| Scan mode | 1/16scan |
| Port type | HUB75-A |
| Brightness of white balance | ≥2800cd/m2 |
| Package of Carton | 467*451*230mm |
| Quantity | 40 pcs |
| G.weight | 13.7kg |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
