| Price: | US $ 500-950/Square Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Square Meter |
| Pay Type: | L/C,T/T |
1. large viewing angle
2. Light weight
3, CE & ROHS Certificates
4.long lifespan
P6 led display specification:
Part Number HERO-IDS4F-8S
Resolution 32(H)×16(V)
Pixel Pitch 6mm
LED Configuration 1R1G1B 3-IN-1 SMD
Pixel Density 10,000pixels/ m2
Module Size 320*160mm
Driving IC MBI5024
Driving Method 1/4 Scan, Constant Current
Cabinet Weight 42kg/sq.m.
Mechanical Ratings
Hanging Weight Support 2T
Surface Flatness Gap<0.5mm
Optical Ratings
Brightness >1,800cd/ m2
View Angle 150°/150°
Gray Scale 8bits input, correction with 14bits
Display COLOR 16.7M
Brightness Adjustment 0~100%
Power Supply
Operation Power 90~260V 50~60Hz
Max. Power Consumption 600W/ m2
Average Power Consumption 200W/ m2
Control System
Control Mode Synchronous display with control PC by DVI
Frame Update Frequency 60~85Hz
Screen Refresh Frequency 300~1000Hz
Gamma Correction -5.0~+5.0
Support Input Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode 1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction Pixel, Module, Cabinet
Environmental
Operating Temperature -20°~+60°
Operating Humidity 10~95% RH
Operating Life 100,000hours
MTBF 5000hours
Protection Level ~
Out of Control Rate <0.02%
| Prod Model: | P6 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lifespan: | 100,000 Hours |
| Warranty: | 2 Years |
| Display Type: | LED Video Display |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Scanning Mode: | 1/8 Scan |
| Certification: | CCC |
| Pixel Configuration: | 1R,1G,1B |
| Pixel Pitch: | 6mm |
| Application: | Shopping Guide |
| IP Rating: | IP43 |
| System Operating Platform: | WIN XP |
| Pixel Density: | 27,778 Dots/Sqm |
