Product Description
1,The design has the features of "light","thin", "fine", "penetrate ". Convenient installation, withstand wind and dustproof. Application for the stage and surrounding
2,This product has been applicated at many fields such as stage, bar, entertainment TV and so on, it has been shown the unique artistic charm and aesthetic feeling of space imagination.
3,The brightness can be adjusted from 500 nits to 2000 nits without damaging the gray level, matching with calibration technology, it has the great expressive color.
4,The product is with convenient installation, and flight connectors connecting. Now it has become the most popular fashion elements at the digital stage and bar.
5,High refresh frequency can meet the requirement of the shooting on the stage, presents the perfect effect.
| Technical parameters |
Item |
Indoor Fixed LED display Series |
| Pixel Pitch(mm) | 6mm |
| Pixel density(pix/m2) | 27777 |
| LED Type | 3528 |
| Viewing Angle | H:140°,V:140° |
| Color Depth(nits) | 1500 |
| Drive Method | 1/16 |
| Color Depth | 16384 |
| Refresh Rate(Hz) | 1200 |
| Module Size(mm) | 192×192×13 |
| Cabinet Size(mm) | 768×768×133 |
| Cabinet Material | Iron Sheet Metal |
| Cabinet weight(kg) | 32 |
| Voltage | 110/240V |
| Average.power(W/m2) | 120 |
| Max.power(W/m2) | 350 |
| IP Grade | IP31 |
| Operating temperature/humidity | temperature:-20ºC~ 50ºC humidity:10~90%RH |
| Storage temperature/humidity | temperature:-40ºC~ 60ºC humidity:10~90%RH |
| Lifetime(h) | ≥50000 |
| Compliant Standard | CE,FCC,RoHS,ETL,CCC |
Shenzhen LED World Co., Ltd has focused on export business since 2009, who specialized in supplying the solutions of LED display screens, LED signs for worldwide market. The products series include small pixel pitch LED display, rental LED display screen, advertising LED display, stadium LED sign, LED ball screen, LED floor screen, creative LED display screens and so on. The above products are widely used in advertising media, public facilities, sports, entertainment, military, traffic and other industries, exported to USA, Mexico, Greece, Spain, Italy, UK, Thailand, Uganda, Nigeria, Russia, India, Turkey, Thailand, Vietnam, Brazil, Australia etc more than 20 countries and regions, and gained good reputation form the clients.
LED WORLD depends on the excellent outstanding R&D technicians, skilled & experienced oversea sales team, who adhere to" customer first, quality first, reputation first" as operating principle, making our future is better and better day by day.
Warmly welcome you visit our company to innovate and win glory together.
