| Price: | US $ 1-1200/Square Meter |
|---|---|
| Trade Terms: | FOB,CIF,FCA |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
Products details
1. High brightness which is adjustable to sufficiently meet the needs of various application environments.
2. The raw material of all of the outdoor products including LED chips, mask, glue and steel cabinets have the ability of enduring high temperature and high humidity, and being anti-UV, waterproof, anticorrosion and antirust.
3. Every production process is well controlled and all of the electronic components are covered by 2mm Tri-Guard Lacquer to ensure no oxidation, no rusty and no moisture. Five-Guard Lacquer will be used for special requirements
4. All of the cabinets are tested by flush, shower and soaking, to ensure the waterproof grade in front side to be IP65 . .
5.Display even after long-term use of perfect quality reproduction and enough brightness and white balance.
Application and function
Suit for advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.
1) Video display for advertisement
2) Live broadcast for news, sport, concert
3) Stage background
4) Information display for time, schedule, text
5) Dynamic display for logo, text, video
| No. | Type | Full Color |
| 1 | Pixel Configuration | 1R+1G+1B |
| 2 | LED Type | SMD3528 |
| 3 | Module Resolution | 32pixels(H) ×32 pixels(W) |
| 4 | Module Dimension | 160(H) ×160 mm (W) × 160 mm (L) |
| 5 | Power Consumption(average) | 550w/ m 2 |
| 6 | Power Consumption(max) | 900 w/ m 2 |
| 7 | Density | 40000pixels/m 2 |
| 8 | Brightness | >2500 nits |
| 9 | Color | 16.7 M |
| 10 | Brightness Control | Manual/Auto |
| 11 | Gray Scale Rectification | r rectification |
| 12 | Picture Regulation | Contrast/Chroma regulation/Module brightness regulation |
| 13 | Drive Mode | 1/8 duty |
| 14 | Refresh Rate | 960HZ |
| 15 | Control Mode | Synchronization control |
| 16 | Video Interface | S-Video, VGA, DVI etc. |
| 17 | Life Time | 100,000 hours |
| 18 | Mean Time To Failure | >10,000 hours |
| 19 | Blind LED | None |
| 20 | Working Temperature | -35 °C ~+ 55 °C |
| 21 | Relative Humidity | 10%-95%RH |
| 22 | Display Flatness | The display : ± 1mm Gap between modules : 1mm |
| 23 | Display Information | Text, Video and Picture etc. |
| 24 | Voltage | 220V ± 10% , 380V ± 10% |
| 25 | Communication Distance | < 20km |
| Prod Model: | GTC- p5 -105 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: | 240mm X 120mm |
| Module Resolution: | 40000dots/Sqm |
| Package Mode: | SMD3528 |
| Max Power Consumption: | 25W |
| Gross Weight: | 0.21kg |
| Module Thickness: | 17.12mm/29.33mm |
| Warranty: | 2 Years |
| Display Type: | LED Video Display |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Scanning Mode: | 1/16 Scan |
| Application: | Advertising |
| Pixel Configuration: | 1R,1G,1B |
| Pixel Pitch: | 5mm |
| IP Rating: | IP43 |
| Certification: | CCC |
| Pixel Density: | 40,000 dots / m² |
| System Operating Platform: | WIN XP |
