Home LED Light Products P5 High Cost-Effective Indoor LED Displays

P5 High Cost-Effective Indoor LED Displays

P5 High Cost-Effective Indoor LED Displays
Price: US $ 903/Square Meter
Trade Terms: FOB
Min Order: 5/Square Meter
Pay Type: T/T
P5 Indoor electronic LED Screens for Advertising Media, Sports Stadiums

Specitication:P5 LED Panel Specification
NO:Product NameSpecification
1Pixel Pitch5mm
2Pixel Configuration1R1G1B/SMD3528
3Density40,000 pixel/m2
4Moduel Size(L×W)mm160mm×160mm
5Cabinet Size(L×W×H)mm640mm×640mm×130mm
6Module Resolution32×32
7Cabinet Resolution128×128
8Driving Method1/16 Scan
9Driving ICMBI5024
10Brightness1500cd/m2
11Contrast1000:01:00
12Brightness AdjustmentAC 85-264V
13Power ConsumptionMax Power:<1000W
14Average power: <350W
15Cabinet Weight<14kg
16Color Temperature3200K-9300K
17Horizontal Viewing Angle120º
18Vertical Viewing Angle90º
19Signal Processing10 or 14bit
20Grey Processing1024×1024×1024
16834×16834×16834
21Control DistanceCable100m,Multimode500m,Single mode
2km
22Frame Frequency60 Hz
23Refresh Rate>600Hz
24Control ModeSynchronous/Asynchronous
25The Opposite Calibration CurveWith Eight Optional Gamma Calibration Curve

26Users can choose the recommended curve, also can be adjusted according to actual situation

27MTBF≥50000 hours
28Life Span100,000 Hours
29Operating TemperatureWorking : 35 - 90 °C
30Storage : 10 - 99 °C
31Environment Temperature-30°C to 60°C; humidity Rh10% to 95%
32Remote ControlCan realize remote control,For the possibility of potential failure logging, and send alarm signal to the operator (need to customize)

33Self-checking TechniqueLED a single point of self-inspection, communications test, power test, temperature monitoring (need to customize)

34System Operating PlatformWindowsNT,Windows2000,WindowsXP,Windows7
35Power SupplyAC 85-264V
36Protectionwaterproof, dustproof, high temperatureproof,anti-corrosion, anti-burning,anti-static,shake proof,thuner-proof,the system with smoke alarm and temperature alarm function. (need to customize)


Company introduce:

Shenzhen Teeho Optoelectronics Co.,Limited is one of leading  high-tech manufacturer for led display , led lighting and related LED photoelectric engineering. Our factory covers an area of nearly 10,000 square meter, monthly production reach to 8,000 quare meters of LED display with 15 sets high-speed SMD machine.


Mass production ensures the uniformity and stability of all raw materials. Through resource integration,comprehensice integrated solutions, we providing more thoughtful services to our customers with ensuring the products quality and reduce cost effectively.


"Staff are first ,customers are highest "is the basic philosophy that we'v been insisting since Teeho founded. Our company aim to build a team like wolfs with ability of learning-oriented,high execution ,cohesion. Library was been set up for staff learning and relaxation .We also set up volunteer team to reveal enterprise positive energy.  Company's overall image  and working environment and positive energy has attracted a group of senior technological team and formed from the  LED components to the LED terminal product research and development, manufacture complete industry scale.



Our products Teeho displays in the rapidly expanding Chinese market at the same time, has towards the international market, and the share of export gradually increasing.(all of our products passed RoHS/CCC/CE/EMC/ISO /FCC certifications. The LED application product variety is complete which researched and manufactured by our company, the product structure diversifyion. Including: cover the indoor and outdoor series. such like: 1.rental display;2.advertising LED display;3.LED TV;4.full color anomalous display etc.Products are widely used in various public places: such as commercial plaza, government agency, stadiums, transport facilities,financial institutions, theater, performance hall, etc. Our products are exported to the United States, Europe, southeast Asia and other countries,Hong Kong, Taiwan and other regions. With international standards of production process, strictly control product quality and won the customer consistent high praise.



Through the ways like cooperation with local customers, set up offices in local, SungreenLED have set up a batch of after-sales service which can rapidly solve problems. For rapid response, to quickly solve customer problem, personalized solutions. Make the products and services reflect personalized, comprehensive, long cycle, less defects.



Teeho  is located in Shiyan Town, Baoan district, Shenzhen. Positive response national green environmental protection, energy conservation and emission reduction policy in developing process. We continue to focus on the LED display, striving to become the world's highest cost-effective LED supplier, the solution to the overall service, with the attitude of a new high-speed development in LED display industry.

Services:

TeehoLED always pay attention to good service to our customers ."Honest, pragmatic " are our service philosophy and basic principle, also are our promise to our clients.



Pre-sale Services:



1.Provide free consulting, to resolve the confusion from customers and supply technology services free by telephone;

2.Mining and carefully study customer's needs,provide detail and suitable design solutions according to the actual installation environment;



In-sale Services:



1.Try best to meet the reasonable demands by customers;

2.Keep close touch with our clients during the period of installation;

3.Cooperate friendly with client and satisfy our clients with best quality LED display.



After-sale Services:



1.We provide free training to our customers on how to install the LED display, as well as the display system operating;

2.Provide 2-year guarantee for normal products free;

3.Clients can down load and upgrade the related operating software of the LED display freely from our company website,so as to resolve the problems during the using time;



4.Regular follow-up service to our customers, solicit opinions from clients and improve the improvement.

Prod Model: PH5
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
LED Chip: Epistar
Power Supply: 5V40A
Cabinets Size: 640mmx640mm
Brightness: More Than 1600nits
Display Type: LED Video Display
Tube Chip Color: Full Color
Display Function: Video Display
Scanning Mode: 1/16 Scan
Certification: CCC
Pixel Configuration: 1R,1G,1B
Pixel Pitch: 5mm
Pixel Density: 40,000 dots / m²
Application: Rental Usage, Wedding.
IP Rating: IP43
System Operating Platform: Winxp, Win2000, Win98, Win7,Win8,Mac
Shenzhen Teeho Optoelectronics Co. Ltd(short for Teeho Optoelectronics), found in 2009, is a high-tech private enterprise specialized in LED Screens manufacturing with a ¥ 11 million of registered capital and over 300 employees in Shenzhen. It has been dedicating itself to offering one-stop LED display solutions to its customers including R&D, prototyping, assembly, sales and technology support across the globe.

Teeho industrial park is located in Bao'an, Shenzhen, the most populous LED industrial area, with a cover of more than 10, 000 m2 and over 300 million of amount of sales per year, fully equipped with modern automatic assembly lines with the manufacturing capabilities of 8000 m2 per month

Teeho Optoelectronics spans a wide range of products covering: Indoor Full-Color LED Displays, Out Full-Color LED Dislays, LED Television Displays etc, applied to governmental institutions, corporate image projects, business ads, media activities, cultural and entertainmental places, stadiums, stations and airports etc.

Teeho Optoelectronics is focusing all efforts to technology-leading strategies of production by relying on the three-tier talent strategy, gathering high profile professional talents, which makes a foundation of new R&D of products and specially custom-made products. The R&D teams of Teeho electronics have been dedicating themselves to one-stop solutions, and have obtained tens of certifications of products and innovative patents. Moreover, they have outstandingly achieved in high-end indoor full color display solutions.

Teeho electronics has been promoting itself by advanced technology and scientific managements and has the following certifications: ISO9001: 2008 Quality System Certification, ISO1400: 2004 Environment System Certification, CCC, CE, FCC, RoHS etc. With high quality and perfect service, Teeho Optoelectronics has built lots of sales and service networks and its high-quality products has been exported into more than 80 countries and areas such as the United States, India, New Zealand. Japan, Thailand, Taiwan and Hongkong.

Teeho Optoelectronics Co., Ltd has been marching on under core values of Integrity, Pragmatic, Harmony, Creativity to guide our staff members and to devote itself to leading status in this industry, to ensure that our client will be fulfilled with the high-quality products and best service. With the horizontal developments in industrial chain and a variety of for-profit models, we vigorously promote the construction of brand culture, strive to become a world-class brand researched and developed independently, to become the most professional LED screens and one-stop solutions supplier, which makes a contribution to competing of national brands in globe markets.
